Carry-on Digitale Blasinstrument 2 Schnellstartanleitung

I N T R O D U C T I O N
Welcome to your Carry-on Digital Wind Instrument 2.
Please take the time to read through this manual to ensure you
get the best use from your new digital wind instrument.
What's included:
Carry-on Digital Wind Instrument 2
Soft case
Removable silicone mouthpiece
USB-C to USB-A charging cable
Carry-on Digital Wind Instrument 2 user manual
F E A T U R E S
The Carry-on Digital Wind Instrument 2 can be played just
like a traditional instrument, with features to enhance your
playing experience.
10 built-in Voices
3.5mm headphone output for silent practice
Built-in speaker
Reverb effect
MIDI over Bluetooth for use as a wireless MIDI Controller
on iOS and macOS
Built-in rechargeable lithium battery for up to 3 hours of
continuous use
Transpose pitch by 12 semitones up or down
Two fingering modes
Removable silicone mouthpiece
Supplied with a soft case and USB charging cable
V O I C E L I S T
1. Alto Saxophone 6. Bassoon
2. Trumpet 7. Violin
3. Trombone 8. Hulusi
9. Chinese Bamboo Flute
4. Flute
5. Clarinet 10. Erhu
ACTIVATE YOUR VIP ACCESS
EXCLUSIVE REGISTER BE THE FIRST
CONTENT YOUR PRODUCT
TO HEAR
268400M-VA-A 03/24
I N S T R U C T I O N S
MOUTHPIECE: Attach the silicone mouthpiece cover
over the mouthpiece.
POWER: Hold the Power button to turn on your Digital
Wind Instrument.
VOICE: Press the Voice button and then use the
V
Function buttons to select your instrument sound.
REVERB: Press the Reverb button and then use the
R
Function buttons to select on or off.
TRANSPOSE: Press the Transpose button and then
T
use the Function buttons to transpose your
instrument up or down 12 semitones.
VOLUME: Press the Volume button and then use the
Function buttons to select your volume.
FINGERING: Hold down the Transpose button until the
T
screen displays 'F1'. Use the Function buttons to select
Fingering 1 (Saxophone) or 2 (Chinese flute).
BREATH SENSITIVITY: Breath Sensitivity refers to the
amount of air pressure required to generate a loud sound.
The higher the sensitivity means less air pressure is needed to
make the note louder. To select Breath Sensitivity, hold down
theVolume button until the screen displays 'b1'. Use the
Function buttons to select between breath sensitivity 1
(low), 2 (medium) or 3 (high).
BLUETOOTH: Hold down the Bluetooth button
to
turn the Bluetooth MIDI function on or off. To connect your
mobile device to your instrument, please do not try to
connect through your standard Bluetooth settings. Instead,
you will need to connect via your chosen music app to
pair with your device. Go to the Settings menu in your
chosen music app to connect your digital wind instrument.
Using GarageBand as an example, go to:
Settings - Advanced - Bluetooth MIDI Device
Find 'Carry-on DWI 2' in the Devices list and tap to connect.
When the Bluetooth button indication stops flashing and
remains lit, the connection is complete.
NOTE: The connection is BLE-MIDI data. Audio streaming to
Bluetooth headphones or other speaker devices is not supported.
EXIT: To exit a setting, press any button apart from the
Bluetooth button. This will take you out of the current action.
SIMPLY
REGISTER
YOUR
PRODUCT
BE A KEY
www.carryonplaying.co.uk/vipaccess
INFLUENCER
B A T T E R Y
This product has a built-in rechargeable lithium battery, which
can support up to 3 hours of use from full charge under
normal conditions.
Press the Power button to display the remaining power.
When the battery power is low, the power LED will flash to indicate
low power.
Continual use of the product while the battery power is low may
impair its performance and can decrease the life span of the
battery. Please connect and charge the product with a suitable
power supply immediately.
To charge the device, always use a suitable USB charger connected
to the USB-C port. The power LED will flash slowly to show that your
device is charging. The power LED will stop flashing once the
battery is fully charged.
To save power, the unit will automatically shut down after 15 minutes
of inactivity.
F A C T O R Y R E S E T
Press and hold the Voice button whilst powering on the device
V
to perform a factory reset. The screen will flash 'r5' several times then
wait for the home screen to load then use as normal.
P R E C A U T I O N S
To avoid electric shock, short circuit, accidents, fire, or other
hazards, please pay attention to the following important information:
Do not dissemble, squeeze or throw the battery into a fire. If the
battery swells, please do not continue to use the device.
Ensure that the internal battery pack is not exposed to excessive heat.
Keep away from fire, hot surfaces, direct sunlight or other ignition
sources.
Please keep your Carry-on Digital Wind Instrument 2 away from rain,
water or any other wet environment.
Please dispose of the used battery following local recycling laws.
Please do not open your Carry-on Digital Wind Instrument 2,
dissemble its parts or make any changes to the internal components.
This product has no parts that can be repaired or altered by an
untrained professional.
If you notice abnormal behaviour with your Carry-on Digital Wind
Instrument 2's functions, please contact an official service centre.
Before cleaning your Carry-on Digital Wind Instrument 2, turn off the
power and disconnect all cables. Do not clean your Carry-on Digital
Wind Instrument 2 with a corrosive solvent.
This product is not suitable for children under three years of age.
DIGITAL WIND INSTRUMENT 2 CONTAINS
MODEL: 268100-VA / 268100-VB FCC ID: 2AXTO-AC695X
Bluetooth module model no.：AC695X IC: 21116-AC695X
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation. CAN ICES-3 (B) / NMB-3 (B)
PLAY
ANYWHERE.
Screen
Function Previous Function Next
Voice Reverb
V R
Transpose Volume
T
Power Bluetooth
Octave Shift
Removable
Mouthpiece
Cover
For hygiene
reasons, please
regularly wash the
removable
mouthpeice cover
in warm, soapy
water. Dry
thoroughly before
refitting.
DESIGNED IN
Power LED
Serial
PARTNERSHIP WITH
CARRY-ON UK
Number MADE UNDER LICENSE
IN CHINA Speaker
Your serial number
BATTERY CAPACITY:
is located here. To 800mAh
USB
assist with any
warranty needs,
this number will
Headphone
be required.
Finger Holes
Drain Hole
