XLOCK 10 MifareFlex Produktblatt

// INCLUDED PARTS
Lock XLOCK 10 MifareFlex
Mounting Lock, screws, locking part
// IMPORTANT INFORMATION
• We recommend that you use lithium batteries for all our products.
• Do not insert the battery until before commissioning.
• To avoid interference between the locks, keep a minimum distance of 10 cm when
installed, or the battery can otherwise be quicker discharged.
• A minimum distance is mandatory for storage. Do not insert the battery until
before installation.
• RFID reading distance for Mifare Classic key fobs up to 25 mm. For Mifare Classic
cards up to 30 mm. For Mifare Desfire media, we recommend recessing the
antenna or using an external antenna. See technical details for reading distance.
• Always check the reading distance with the customer transponders before and
after installation!
*The battery lifetime depends on the temperature and the usages.
// RESET
You can do a hard reset of the lock. To do so, press the
reset button as shown on the picture for 3 seconds
until a long sound arises.
// MAINTENANCE
• Use only a dry and soft cloth for cleaning.
• Do not use any cleaning agents or chemicals.
• Store the product in a cool and dry place.
• Store the product out of reach of children and in a dry and dust-protected
environment when not in use for a longer period of time.
• Keep the original packaging for transport.
// DISPOSABLE INFO
According to the European WEEE Directive, electrical and electronic
equipment must not be disposed of with household waste. Their components
must be recycled or disposed of separately, because toxic and hazardous
components can cause lasting damage to health and the environment if disposed
of improperly. As a consumer, you are obliged under the Electrical and Electronic
Equipment Act (ElektroG) to return electrical and electronic equipment free of charge
at the end of its service life to the manufacturer, the point of sale or to public collection
points set up for this purpose. Details are regulated by the respective state law. The
symbol on the product, the operating instructions and/or the packaging indicates these
regulations. By separating, recycling and disposing of old equipment in this way, you are
making an important contribution to protecting our environment.
© XLOCK. Errors and misprints excepted.
Product sheet - English
XLOCK 10 MifareFlex
// TECHNICAL DETAILS
Lock: 89 x 63,5 x 28.5 mm
Size
Locking part: 43 x 40 x 20 mm
Weight ca. 200g (locking part, battery, screws)
Temperature -10°C to +55°C
Battery CR123A battery
Battery life Up to 20,000 openings, 2+ years*
RFID
13,56 MHz Mifare®, NFC, LEGIC ISO14443a
frequency
Accessibility RFID
Mode 1: Fixcode NFC automatic locking after 4 seconds
Mode 2: Fixcode NFC Open/Close, no automatic locking
Operating Mode 7: Freelocker Mifare Classic (0 hours)
mode Mode 8: Freelocker Mifare Classic opening after XX hours
Mode 9: Freelocker NFC (0 hours)
Mode 10: Freelocker NFC opening after XX hours
3 programming cards, 47 user cards, 5 emergency opening cards,
Programming
Service card for each Mode
MIFARE® and ISO 14443A: MIFARE Classic® 1K and
RFID 4K, MIFARE Ultralight®, MIFARE® Mini, MIFARE Plus®,
transponders MIFARE® DESFire®, MIFARE® SLE66R35, LEGIC® advant
ATC2048 and ATC4096, My-D NFC
Reading RFID: up to 25-30 milimeters depending on the quality of the
distance ID cards.
// GUIDES AND MORE
Please scan the QR code with your Smartphone and a
website with all the information will open.
If you are working on a PC, you can click on the QR
code and a website with all the information will open.
// PACKAGING
Packaging can be disposed free of charge at the appropriate collection points -
paper in the paper garbage can, plastics in the yellow bag and glass in the used
glass container.
XLOCK is a registered trademark of XLOCK GmbH, declares that the product
meets the essential requirements and directives European regulations.
