DE
Die Führungsschiene sollte vor der Installation in den Pfosten eingeführt werden,
Installationsrichtung wie im Bild gezeigt. Der Vorhang kann auch auf dem Balken installiert
werden, bevor der Rahmen umgedreht wird.
EN
Guide rail should be inserted into the foot tube before installation, installation direction as
shown in the picture. Roller shutter can also be installed on the beam before the frame is
flipped.
Bestreichen Sie die innere Ecke der Nut mit einer Ölschicht,
Brush the inner corner of the groove with a coat of oil before
bevor Sie sie einsetzen.
inserting
Pfosten & Führungsschiene
Foot tube & Guide rail
Griffposition
Handle location
3
