Crydom 1F25 Kurzanleitung Seite 2

SPECIFICATIONS
Description
Model Number
Connection (number of phases)
Maximum Operating Voltage
Operating Temperature Range
Attenuation (150 to 250 Khz), typical
Current Drain at VRMS max
GENERAL NOTES
1) All parameters at 25°C unless otherwise noted.
WIRING DIAGRAM
Single Phase
INPUT
4
SSR
FUSE
PROTECTION
L
1
1F25
FILTER
N
MECHANICAL SPECIFICATIONS
Do not forget to visit us at:
Copyright © 2018 Crydom Inc. Specifications subject to change without notice.
AC Filters
EMI noise suppression filters for SSRs in:
• Single-phase and
• Three-phase systems
3
2
LOAD
www.crydom.com
DataSheet
1F25
Single
275 VRMS
30 dB V
40 mA
Three Phase
INPUT
SSR
FUSE
PROTECTION
LOAD
1
A1 A2
2
B1
B2
3
C1
C2
3F20
4 WIRE - 3F20-A
FILTER
FOURTH WIRE (Neutral)
Accessories
3F20-4
3F20
Three (w/neutral)
Three
475 VRMS
475 VRMS
-40 to +100 ° C
25 dB V
25 dB V
35 mA
35 mA
Rev. 030118
ECN#20419
