1-3 Need Spacer?
No, choose suitable screws and washers.
a
c
b
k l
Yes, choose suitable screws, washers and spacers.
d
e
f
k l
g
j
i
h
Tips: If you need to combine M6/M8(c/e/f) screws
with 2.5mm spacers( i ), you have to remove the
inner circle.
screw
c
is connected
with TV Plate
04
directly,do not need to
be connected with
Washers
.
k
l
screw
f
is connected
with TV Plate
04
directly,do not need to
be connected with
Washers
.
k
l
1-4 Attach the TV Plate
⑤
③
③
④
②
②
①
①
①
①
④
②
②
⑤
③
③
04
Please ensure that all four screws enter the
VESA hole before tightening all screws during
installation.
⑤
① 75X75
④
② 100X100
③ 100X200
④ 200X100
④
⑤ 200X200
⑤
No!
7
