AlzaPower APW-HCC7B 140 Serie Bedienungsanleitung Seite 5

TECHNICAL SPECIFICATION
Input
Outputs
HDMI output parameters
USB-A output parameters
USB-C
DP1.4 Alt mode support
Backwards compatible with DP1.2 Alt mode
Note: For maximum bandwidth, the connected device
must support DP1.4 mode (available on laptop models
released 2019 and later).
1× HDMI (max. 4K/60 Hz)
2× USB-A 10G
1× Ethernet
1+1× SD/microSD
1× USB-C PD (140 W)
Support max. 4K / 60 Hz video output
8/10/12 bit colour depth support
Formats supported: RGB; YCbCr 4:4:4; YCbCr 4:2:2;
YCbCr4:2:0
HDCP2.3, HDCP2.2, and HDCP1.4 support
HDR support
Total output of both USB-A ports is up to 12 W (5 V / 2.4
A). One USB-A port (the one near the SD/micro SD slot)
supports charging at up to 7.5 W (5 V / 1.5 A), while the
other supports up to 900 mA
Maximum data transfer rate is 10 Gbps per USB-A port
Short circuit protection, over-current protection
ENGLISH 5
