D
-
7
Front Swaybar
Bag
Stabi vorne
T08606 M3x3
T08601
Swaybar Mount
Stabihalterung
T08674 M2.5x8
T08601 M3x3
T08674 M2.5x8
-
8
Front Hub Carrier
Bag
Achsschenkel vorn
T08639
95.5mm Front CVD
95.5mm CVD Welle vorne
T08639 5x8.5
T08639 2.5x12.8 Pin
..................2
T08665 13x19x4 Ball Bearing
Kugellager
.........2
T08664 8x16x5 Ball Bearing
Kugellager
.........2
Assemble both Left and Right
L
R
Beide Seiten (links/rechts)
auf die gleiche Weise montieren
T08647
Front Swaybar
Stabi vorne
D
T08639 2.5x12.8
T08639 5x8.5 CVD Shaft
CVD Schaft
........................2
T08603 King Pin Bushing
Blockhalterung
.........4
T08649 2.5x16.8 Pin
...............2
T08639 M4x4 Screw
Schraube
.....................2
T08673 M4x14 Screw
Schraube
......4
Assemble as many times as specified So oft montieren wie angegeben
x2
T08606
x2
Left
Front Hub Carriers 12 Degree
T08603
Achsschenkel vorne 12 Grad
T08639
T08665 13x19x4
T08673 M4x14
L
R
4
T08674 M2.5x8 Screw
T08601/T08606 M3x3 Screw
T08606 6.8 Ball stud
T08606 6.8 Ball stud
T08606 6.8 Ball End
T08604
Right
Steering Block-Left
Lenkhebel links
T08603
King Pin Bushing
Blockhalterung
T08664 8x16x5
T08649
Wheel Hex Hub
Radmitnehmer
Schraube
..................3
Schraube
........................4
Kugelkopf
.....................2
Kugelkopf
...........................2
Kugelpfanne
..................2
Steering Block-Right
Lenkhebel rechts
T08649 2.5x16.8
T08639 M4x4
