Note
Mission time
Klassifisering - Feilutelukkelse
Please note:
Performance Level, up to
Category
Note
Mission time
Klassifisering - forriglingsfunksjon
Performance Level, up to
Note (Performance Level)
Mekaniske data
Mekanisk levetid, minimum
Aktivatordødgang i aktiveringsretning
Klemmekraft iht. EN ISO 14119
Klemmekraft, maksimum
Holdekraft
tvangsbrytende vandring
Positive break force per NC contact, minimum
Tvangsbrytende kraft, minimum
Aktueringshastighet, maksikum
Montering
Type of the fixing screws
Type of the screw head
Mechanical data - Connection technique
Kabelføring
Konnektor stikk
Kabeldimensjon, minimum
Kabeldimensjon, maksimum
Note
at 10% I and ohmic load
e
20 år
Can be used when fault exclusion for dangerous damage to the 1-
channel mechanism is permissible and sufficient protection against
manipulation is guaranteed.
d
3
for 2-channel use and with suitable logic unit.
20 år
e
Information for the safety classification of the guard locking
function is documented in the "Operating instructions" or in the
"Operation and mounting" instructions.
1 000 000 bevegelser
5,5 mm
2 000 N
2 600 N
30 N
10 mm
10 N
20 N
2 m/s
Skruer
3x M5
Flat head screw
4 x M16 x 1,5
Fjærtilkopling
0,25 mm²
1,5 mm²
Alle indikasjoner om kabelsnittet inkluderer lederhylsene.
5-18
