Product Overview
Product Layout
Front Panel
No. Part Name No.
1 Smart Knob 7
2 LED Indicator 8
3 LCD Display 9
4 OK/Menu Key 10
5 Back/Subgroup Key 11
6 P6/End Key 12
Rear Panel
No. Part Name
RF Antenna
1
Connector
2 Power Inlet
Accessory
3
Connector
NOTE
The GPS antenna connector is used only by radios
with the GPS feature.
Palm Microphone
Push-to-Talk
(PTT) Key
Part Name
On-Off Key
Navigation Key
Speaker
Aviation
Connector
P5/Answer Key
Programmable Keys
Top Key
Aviation Port
Ke
NOTE
The palm microphone without keypad is available
for the conventional radio and the one with keypad
is for the trunking radio.
Programmable Keys
No. Part Name
GPS Antenna
You can request your dealer to program the following keys as
4
Connector
shortcuts to assignable radio features:
●
5 Network Port
/ /
●
Installation
Instructions
Before installing the radio in a vehicle, read the following
instructions carefully:
●
Microphone
Buckle
●
●
Buckle
Push-to-Talk
●
(PTT) Key
P1
P2
●
Aviation
Connector
●
●
●
1
Radio: TK, P1 key, P2 key, P3 key, P4 key, P5/Answer
key, and P6/End key.
Palm microphone with keypad: TK, P1 key, and P2 key.
Before installation, check the ground polarity and
voltage of the vehicle power. The radio must work with a
13.6 V±15% negative ground electrical system.
Before installation, check how long the screws will
extend from the bottom surface of the radio. Drill the
mounting hole cautiously to avoid damage to the vehicle
wiring and other parts.
Before you install the radio in the mounting bracket,
connect the antenna and power cord to the radio. Use
the dedicated antenna and power cord provided by the
Company for digital radios.
Install the radio with the mounting bracket supplied by
the Company, to avoid accidental radio looseness. The
loose radio may cause bodily injury.
Install the radio in a location where you can reach the
front panel conveniently.
Keep sufficient clearance at the back of the radio for
wiring.
Use the fuse with the same specification for DC power
cord upon replacement.
If any other devices are in the vicinity of the radio, keep
the antenna of these devices at least 10 m away from that
of the radio.
