INTRODUCTION
This 2.5" IDE to Dual Compact Flash Drive is an economical choice to use Compact Flash (CF) memory card as a
2.5'' IDE storage device. Once being installed into PC/laptop, the CF appears as an ordinary IDE HDD to any
operating system and can be configured as a boot device. The IDE interface supports Ultra-DMA host port. The
CF interface supports up to two Ultra-DMA CF Type I cards and capable of transferring data up to 150M Bytes/sec.
The versatility and the high performance of this product make it an ideal CF read/write device for many industrial
PCs and embedded systems applications.
FEATURES AND SPECIFICATION
General
•
Standard 2.5'' IDE storage device form factor (100.2mm x 69.9mm x 9.8mm)
•
LED indicators: Power On, Master / Slave Card Detect, and Disk Activity
•
Can be a primary bootable device containing the O/S and applications (depends on CF card specification)
•
Transparent to operating system and does not require any drivers
•
Supports Microsoft Windows 2000, XP 32/64-bit, Server 2003 32/64-bit, Vista 32/64-bit, Server 2008 32/64-bit,
and Linux operating systems
•
Power supply via IDE interface (44-way SFF IDE connector, +5V)
IDE Interface
•
44-way SFF (Small Form Factor) IDE connector
•
Supports Ultra-DMA IDE interface
•
Does not support hot swap on the IDE interface
CF Interface
•
2 X CF card sockets (Master / Slave) supporting CF Type I form factor
•
Supports PIO mode, DMA and Ultra-DMA mode with data transfer rate up to 150M Byte/sec (depends on CF
card speed)
•
Does not support hot swap on CF interface
Package Contents
Please check whether the package contains the following items. If any item is missing or damaged, please contact
the retailer as soon as possible:
•
2.5" IDE to Dual Compact Flash Drive x 1
•
User manual x 1
Product Overview
Top side:
U s e r M a n u a l
Article number 76621I
