ROWENTA TURBO SILENCE EXTREME+ VU589 Serie Bedienungsanleitung Seite 18

TURBO
EN
SILENCE
EXTREME +
Thank you for
choosing a Rowenta
fan. Your fan is
equipped with the
latest Rowenta
technology.
Read the manual
carefully to make the
most of your new fan.
Scan this code with
your phone or QR code
reader to see how to
assemble your fan.
18 18
Y OUR FA N DOE S NO T C OME A S SEMBL ED. I T
IS V ERY IMPOR TA NT TH AT IT IS A SSEMBLED
CORRECTLY.
ASSEMBLY
Overview
1
2
3
4
1- Logo plate
2- Front grid
3- Propeller clamp ring
4-Propeller
5- Grid clamp ring
6- Back grid
7- Motor housing
8- Remote control storage
9- Control panel
10- Adjustable foot
11- Foot
12- Base
13- Washer
14- Fixation screw
5
6
7
8
9
10
11
12
13
14
