Olymp LavaSit DINER Montageanleitung Seite 6

Mounting instructions for appliance fitters
11. Assembly:
11.1 Loosely bind the 2 pressure hoses (hot + cold) and
drain hose together using cable ties.
11.2 Hang the backside cover (1) onto the base:
Hold the cover at the front edge from both sides,
pull apart and draw it from the rear side onto the
base: Front edge of cover must engage in
perpendicular profile.
11.3 Put in the front cover (2) under the seat.
11.4 Attach the mounting strip (5) for installation tunnel
onto the backside cover over the cutout (fig. 2).
11.5 Attach the mounting strip (5.1) for installation
tunnel onto the wall (fig. 3).
Shorten the installation tunnel on the wall side if
neccessary.
11.6 Lay the installation tunnel onto the mounting strips.
Caution:
The ends of the installation tunnel must be fitted
with edge protection!
11.7 only with in-line installation:
Attach mounting strips (5) for installation tunnel
onto the backside cover over the cutout at both
units (fig. 2).
Lay the installation tunnel onto the mounting strips.
Caution:
The ends of the installation tunnel must be fitted
with edge protection!
Diner MO oM W+R
GB
