Beinlich R18 Bedienungsanleitung Seite 28
Düsenwagen
Verfügbare Sprachen
Verfügbare Sprachen
Tafel 9 SIME JUMBO Teso 6° Sektor Regner
Item
Beschreibung
01
Sprinkler body
Inner Sleeve
1a
2
Sectoring arm
3
External rotator body
4
Internal rotator body
6
Thrust washer
7
Top cover
8
Spring
9
Spring tensioner
10
Bottom spring
10a
Spring cover
11
Thrust washer
11a
'O' ring
12
'O' ring
Thrust washer
13
13a
Thrust washer
14
Nozzle
17
Jet breaker mount
17a
Jet breaker screw
18
Sector adjuster
19
Sector adjuster
020
Reversing arm complete
021
Sector striking block complete
22
Spring stiffener
23
Spring
25
Back cover
26
Locking screw
26a
Spring
27
Spacer
28
Nut and bolt
28a
Nut and bolt
29
Reversing pivot pin
Pivot pin
30
31
Split pin
32
Spring
Art. Nr.
Menge
R10224
1
R301086
1
R30598
1
R30273
1
R30387
1
R30296
1
R30297
1
R30298
1
R30299
1
R30281
1
R30284
1
R30391
1
R30276
1
R30392
1
R30391
1
R30393
1
R30280
2
R30307
1
R30308
1
R30288
1
R30288
1
R10102
1
R10103
1
R30313
1
R30314
1
R30316
1
R30317
2
R30325
2
R30319
1
R30320
1
R30321
1
R30322
1
R30323
1
R30324
1
R30325
1
