Installation
1.
Connect the HDMI cable of the Audio Extractor to the HDMI source.
2. Connect the HDMI display to the Output of the Audio Extractor.
3. Plug in the USB power cable to a USB Type-A port or power supply.
a) Connect the TOSLINK output with the digital input of your receiver, or
b) connect the analogue output to the headphone or active speakers.
Operation
When the device is connected, the TOSLINK output will deliver 5.1 channel digital
signals to your receiver. If you plug a headphone into the 3.5 mm audio jack, the
digital output will turn off, and the headphones will get an analogue 2.0 stereo
signal.
