3. Montage des Kühlers
Überprüfen Sie bitte vor der Montage ob
alle Abstandshalter vorhanden sind. Sollte
einer fehlen, so wenden Sie sich bitte an den
Support.
3
Legen Sie zuerst die Wärmeleitpads auf die
Spannungswandler, so dass diese vollständig
abgedeckt werden. Danach montieren Sie
Kühler und Backplates.
Die Wärmeleitpads sind beidseitig mit
einer Schutzfolie versehen. Diese müssen vor
Verwendung entfernt werden!
3. Installation
Please check if all spacers are available
prior to installation. If one should be missing,
please contact support.
First, put the precut thermal pads on the
voltage regulation modules, so that they are
covered evenly. Then, install backplates and
water block.
Both sides of the pads are covered with a
protective film which must be removed before
the installation!
