Active PoE Splitter
User Manual
LINDY No. 25053
www.LINDY.com
For Home and Office Use
Tested to Comply with
FCC Standards
© LINDY ELECTRONICS LIMITED & LINDY-ELEKTRONIK GMBH
English
- FIRST EDITION (Aug 2011)
Radio Frequency Energy, Certifications
Introduction
This Power over Ethernet splitter splits the data and the power from the cable coming over
PSE. When the input port connects to PSE via Cat. 5 twisted-pair cable, the splitter will
pass-through the data signal to its RJ-45 output port and also converter the 48V PoE power
to DC 5V , 7.5V , 9V , 12V output power jack. With this splitter, if a device without PD
features, it also can enjoy the power from PSE.
Package Contents
Before you start to install this PoE splitter, please verify your package that contains the
following items:
One PoE Splitter
One Power Output Cord
One User's Manual
Note: If any of these items is found missing or damaged, please contact your local supplier
for replacement.
Key Features
Complies with IEEE 802.3af, IEEE 802.3 10BaseT and IEEE 802.3u 100BaseTX
TP port supports Auto-MDI/MDI-X and Auto-Negotiation
TP port supports Auto-detect full/half-duplex
TP port is up to 100 meters for the shielded/unshielded twisted pair cable
Supporting up to 5V/2A ; 7.5V/1.4A ; 9V/1.2A ; 12V/0.9A
Smart plug & play
