CENTRIFUGAL SEPARATOR - CARBON STEEL
Fig. 2 --- Overall dimensions (STH001P--- STH003P)
Table 2
Model
STH001P 148
STH003P 142
50
AIR
IN
dimensions (mm)
A B C
280 96
573 128
STH001-046/STH001P-003P
A
D
+
1" BSPT
air in/out
D E
108 ¾" BSPT
108 1½" BSPT
AIR
OUT
weight volume
3
Kg dm
4.5 1.5
8.0 4.0
pressure
bar
40
