CENTRIFUGAL SEPARATOR - ALLUMINIUM
Fig. 1 --- Overall dimensions (STH001--- STH046)
STH001--- 021
A
+
Table 1
Model
STH001
STH002
STH003
STH006 109
STH009 109
STH013 109
STH021 150
STH040 188
STH046 188
½" BSP
dimensions (mm)
A B C
89 267 24
89 267 24
89 267 24
367 34
367 34
367 34
550 41
733 56
733 56
STH001-046/STH001P-003P
air in/out
D E
74 ⅜" BSPT
74 ½" BSPT
74 ¾" BSPT
97 1" BSPT
97 1¼" BSPT
97 1½" BSPT
118 2" BSPT
159 2½" BSPT
159 3" BSPT
STH040--- 046
A
align
+
½" BSP
weight volume
3
Kg dm
1.1 0.8
1.1 0.8
1.1 0.8
2.2 1.8
2.2 1.8
2.2 1.8
4.3 4.9
12.5 10.3
12.5 10.3
pressure
bar
16
