Your authorised dealer or service facili can help rotate the Hybrid Tweeter for you.
To remove the Hybrid Tweeter module from the loudspeaker cabinet, use a 3 mm
Allen key (not included) to remove the four screws. When disassembled, rotate the
Hybrid Tweeter by 90 degrees.
Insert the rotated Hybrid Tweeter and install it using the four screws (Figure 7). Be
careful not to overtighten the screws when reassembling the loudspeaker.
If positioned on a shelf or TV furniture, the enclosed bumpers can be placed under
the loudspeaker (in both the vertical or horizontal position) for stable and vibration-
free positioning (see Figure 4).
The DALI logo on the front grille can be rotated by li ing it up slightly and rotating it
into the desired position (see Figure 6).
4 . 0 C O N N E C T I O N S
Correct, tight connections to your amplifier are extremely important for your listening
experience. Always use cables of the same pe and preferably the same length for
the le and right channels. We recommend using DALI CONNECT loudspeaker
cable, available from your dealer.
Correct polari is a detail that is o en overlooked when connecting loudspeakers.
The red (+) terminal of the amplifier must be connected to the red (+) terminal of the
loudspeaker. The black (-) terminal of the amplifier must be connected to the black (-)
terminal of the loudspeaker (see Figure 9A). In a stereo or surround installation, even
a single loudspeaker connected in reverse polari will make the bass weaker and the
stereo image unfocused.
For the optimal listening experience, the right loudspeaker (as seen from the listening
position) must be connected to the amplifier output terminals marked "R" or "Right".
The le loudspeaker must be connected to the amplifier output terminals marked "L"
or "Le ".
NOTE: Before connecting cables or changing any connections, ALWAYS turn o
your amplifier.
NOTE: Make sure that bare conductors are tightly gripped by the terminals with no
loose wires that could cause a short circuit and damage the amplifier (see Figure 8).
NOTE: If you are using DALI RUBIKORE in a surround system, follow the instructions
included with your surround amplifier.
4.1 SINGLE-WIRING versus BI-WIRING/BI-AMPING
All DALI RUBIKORE loudspeakers can be connected using a single loudspeaker
cable (see Figures 9A and 9B). However, DALI RUBIKORE 2, 6 and 8 are equipped
with two pairs of terminals, allowing you the option of running two sets of cables to
each loudspeaker. The top terminal pair is internally connected to the crossover
network's high frequency section. The bo om terminal pair is internally connected to
the crossover network's bass section.
