NP SERIES - N N P P 7 7 - - 6 6
Reliability is your Security
Yuasa NP, NPC and NPH Batteries. Utilising the
latest advance design Oxygen Recombination
Technology, Yuasa have applied their 80 years
experience in the lead acid battery field to produce
the optimum design of Sealed Lead Acid batteries.
FEATURES
• Superb recovery from deep discharge.
• Electrolyte suspension system.
• Gas Recombination.
• Multipurpose: Float or Cyclic use.
• Usable in any orientation (except continuous inverted).
• Superior energy density.
• Lead calcium grids for extended life.
• Manufactured World wide.
• Application specific designs.
Technical Features
Sealed Construction
Yuasa's unique construction and sealing technique
ensures no electrolyte leakage from case or terminals
Electrolyte Suspension System
All NP batteries utilize Yuasa's unique electrolyte
suspension system incorporating a microfine glass mat to
retain the maximum amount of electrolyte in the cells. The
electrolyte is retained in the separator material and there
is no free electrolyte to escape from the cells. No gels or
other contaminants are added.
Control of Gas Generation
The design of Yuasa's NP batteries incorporates the very
latest oxygen recombination technology to effectively
control the generation of gas during normal use.
Low Maintenance Operation
Due to the perfectly sealed construction and the
recombination of gasses within the cell, the battery is
almost maintenance free.
Layout
www.yuasa-battery.co.uk
Terminals
NP batteries are manufactured using a range of terminals
which vary in size and type. Please refer to details as
shown.
Operation in any Orientation
The combination of sealed construction and Yuasa's
unique electrolyte suspension system allows operation in
any orientation, with no loss of performance or fear of
electrolyte leakage. (Excluding continuous use inverted)
Valve Regulated Design
The batteries are equipped with a simple, safe low
pressure venting system which releases excess gas and
automatically reseals should there be a build up of gas
within the battery due to severe overcharge. Note. On no
account should the battery be charged in a sealed
container.
Terminals
A
Faston tab: 187
.185 ± .004
.020
.059
.031
D D a a t t a a S S h h e e e e t t
General
Specifications
Nominal Capacity (Ah)
20hr to 1.75vpc 30ºC
10hr to 1.75vpc 20ºC
5hr to 1.70vpc 20ºC
1hr to 1.60vpc 20ºC
Voltage
Energy Density
Specific Energy
Int. Resistance (m.Ohms)
Maximum discharge (A)
Short Circuit current (A)
Dimensions (mm)
INCH = MM
Length
.250 6.35
.185 4.70
Width
.124 3.15
Height overall
.098 2.50
.059 1.50
Weight (Kg)
.031 0.80
Terminal
.020 0.50
Layout
.004 0.10
Terminal Torque Nm
NP
NP7-6
7
6.5
6
4.2
6
86.2
(Wh.L.20hr)
28.5
(Wh.kg.20hr)
22.5
35
105
151
34
97.5
1.32
A
1
-
