Elektrische Daten - Magnetansteuerung
Designation, Magnet control
Switching thresholds
Current consumption at 24 V
Magnet switch-on time
Test pulse duration, maximum
Test pulse interval, minimum
Classification ZVEI CB24I, Sink
Classification ZVEI CB24I, Source
Elektrische Daten - Sichere digitale Eingänge
Designation, Safety inputs
Switching thresholds
Current consumption at 24 V
Test pulse duration, maximum
Test pulse interval, minimum
Classification ZVEI CB24I, Sink
Classification ZVEI CB24I, Source
Elektrische Daten - Sichere digitale Ausgänge
Designation, Safety outputs
Rated operating current (safety outputs)
Design of control elements
Voltage drop U
, maximum
d
Leakage current I
, maximum
r
Voltage, Utilisation category DC-13
Current, Utilisation category DC-13
Test pulse interval, typical
Test pulse duration, maximum
Classification ZVEI CB24I, Source
IN
-3 V ... 5 V (Low)
15 V ... 30 V (High)
10 mA
100 %
5 ms
40 ms
C0
C1
C2
C3
X1 und X2
−3 V ... 5 V (Low)
15 V ... 30 V (High)
5 mA
1 ms
100 ms
C1
C1
C2
C3
Y1 und Y2
250 mA
kurzschlussfest, p-schaltend
2 V
0,5 mA
24 VDC
0,25 A
1000 ms
0,5 ms
C2
9-29
