BOERPLAY Shell IPPE013 Installationsanleitung Seite 19

1
/ 1
B
ø3mm x 30
© Copyright BOERplay 25-10-2023
S.IPP.005.K
Detail B (1x)
Revision:
OPE.IPP.058.022
OME.VRB.903.VZP
50 mm
BSR.002.005.050
MOD IPP 011 022
65 mm
A (4x)
Detail A (4x)
BSR.002.006.100
100 mm
x
4 BSR.002.005.050
x
4 BSR.002.006.100
x
1 OME.VRB.903.VZP
x
1 OPE.IPP.058.xxx
x
1 S.IPP.005.x
