Uniq Server Basic
TAN D
BY
REA DY/S
EJE CT
MMC
PRO
MEG6910-0018
fr
Gebrauchsanleitung
de
Operating instructions
en
es
pt
it
nl
sv
no
fi
da
hu
ro
pl
el
ru

Werbung

Kapitel

Inhaltsverzeichnis
loading

Inhaltszusammenfassung für merten MEG6910-0018

  • Seite 1 Telefon: +49 2261 702-235 oder +49 800 63783640 Telefax: +49 2261 702-680 oder +49 800 63783630 E-Mail: infoline.merten@schneider-electric.com TAN D REA DY/S EJE CT Merten GmbH, Fritz-Kotz-Str. 8, 51674 Wiehl, Germany www.merten.com Service Center: Tel.: +49 2261 702-204 MEG6910-0018 Fax: +49 2261 702-136 email: servicecenter@merten.de...
  • Seite 2 READY/STAND EJECT Uniq Server Basic Welcome to Uniq Admin. Welcome to Uniq Admin. Please log in: Please log in: UNIQ UNIQ **** **** Login Login Help with the Uniq Admin site Learn about Uniq at www.uniq Help with the Uniq Admin site Learn about Uniq at www.uniq Configuration Configuration...
  • Seite 3: Inhaltsverzeichnis

    Im Konfigurationstool anmelden ..... 9 MEG6910-0018 Server herunterfahren......10 Fernbedienung .
  • Seite 4: Lieferumfang

    Lieferumfang Lieferumfang Zu Ihrer Sicherheit – Uniq Server Basic GEFAHR! ¼ – AC-Adapter und Netzkabel Lebensgefahr durch elektrischen Schlag. – DVI-VGA-Adapter Alle Tätigkeiten am Gerät dürfen nur durch ausgebildete – IR-Fernbedienung mit Batterien Elektrofachkräfte erfolgen. Beachten Sie die länderspe- – Gebrauchsanleitung zifischen Vorschriften.
  • Seite 5: Uniq Server Basic Kennenlernen

    Uniq Server Basic kennenlernen Systemaufbau und Architektur Uniq Server Basic kennenlernen Maximal kann ein einzelner Server 40 Uniq-Geräte steuern, Der Uniq Server Basic (im Folgenden Server genannt) ist Be- wobei 1 Uniq-Gerät entweder standteil des Uniq-Systems und steuert und visualisiert Ge- –...
  • Seite 6: Anschlüsse, Anzeigen Und Bedienelemente

    Anschlüsse, Anzeigen und Bedienelemente Anschlüsse, Anzeigen und Bedienelemente Vorderseite Ein/Aus-Schalter, grün beleuchtet 2x USB 2.0-Schnittstelle Zum Anschluss von USB-Geräten wie z. B. Tastatur oder Maus. Speicherkartensteckplatz 4-in1 für: SD Memory Card, Memory Stick/Pro, Multimedia Card EJECT Auswurf-Taste für DVD READY/STAND BY IR-Empfänger der Fernbedienung DVD-Laufwerk...
  • Seite 7: Rückseite

    Anschlüsse, Anzeigen und Bedienelemente Rückseite HDMI Anschluss für z. B. Fernseher mit HDMI-Eingang DVI-I Anschluss für einen TFT-Monitor. Mit dem DVI- VGA-Adapter können Sie einen Monitor mit VGA- Anschluss installieren. Netzteileingang, DC 19 V Anschluss für den AC-Adapter (Lieferumfang) LAN-Anschluss, Ethernet RJ-45, Internes Netzwerk für alle Uniq-Komponenten 3x USB 2.0 HDMI...
  • Seite 8: Server Montieren

    Server montieren Server montieren Betriebsumgebung Die Umgebungstemperaturen für den Betrieb liegen zwischen -5 °C bis +40 °C. VORSICHT ½ Der Server kann durch übermäßige Erhitzung be- schädigt werden. • Stellen Sie den Server in einen gut belüfteten und kli- matisierten Raum auf. •...
  • Seite 9: Server In Betrieb Nehmen

    Server in Betrieb nehmen A/V-Wizard Server in Betrieb nehmen 7 Folgen Sie dem A/V-Wizard, mit dem Sie die Audio- und Videoeinstellungen Ihres angeschlossenen Monitors opti- VORSICHT ½ mieren. Der Server kann beschädigt werden. Schützen Sie den Server vor Schäden, die durch Über- Bedienung spannung und Spannungsspitzen verursacht werden.
  • Seite 10 Server in Betrieb nehmen Monitorauflösung prüfen Lautstärke einstellen AV Setup AV Setup Sie sehen die neue Einstellung Sie hören Musik. Step 2 Step 5 Step 1 Step 3 Step 4 Step 5 Final Step 1 Step 2 Step 3 Step 4 Final für ca.
  • Seite 11: Server Mit Pc/Notebook In Betrieb Nehmen

    Im Konfigurationstool anmelden Konfigurationstool aufrufen Uniq Interface aufrufen 8 Wählen Sie auf der Startseite von Uniq Interface: 7 Browser starten: <Internet>  <SYSTEM ADMIN> http://192.168.80.1/uniq-admin/weborbiter.php Server mit PC/Notebook in Betrieb nehmen Konfigurationstool aufrufen 1 Optional: USB 2.0 Fast Ethernet Adapter an eine USB- 8 Browser starten: http://192.168.80.1 Schnittstelle anschließen.
  • Seite 12: Server Herunterfahren

    Server herunterfahren Server herunterfahren Fernbedienung Mit der Fernbedienung können Sie die Benutzeroberfläche WARNUNG ¼ Uniq Interface steuern. Verletzungsgefahr! Damit die Fernbedienung korrekt funktioniert, stellen Sie fol- Um Verletzungen durch elektrische Schläge oder Be- gendes sicher: schädigung des Servers zu vermeiden, müssen Sie den •...
  • Seite 13: Bedienelemente

    Fernbedienung Bedienelemente Schaltet das Gerät aus Wiedergabe einer Mediendatei Startseite aufrufen Schaltet die Wiedergabe auf Pause Lautstärke einstellen Stoppt die Wiedergabe In Listen blättern Schneller Rück- und Vorlauf Ton aus- und einschalten Vorherige und nächste Medien- datei abspielen Musiktitel aufrufen DVD-Menü...
  • Seite 14: Technische Daten

    Technische Daten Anschlüsse, Anzeigen und Bedienelemente Technische Daten Vorderseite: 2x USB 2.0-Schnittstelle Ein/Aus-Schalter, grün beleuchtet System Speicherkartensteckplatz 4-in1: SD Prozessortyp: Intel® Core™ i3 Memory Card, Memory Stick/Pro, Multi- Hauptspeicher: 2 GB SO-DIMM DDR3 media Card Festplatte: 1x SSD 64 GB DVD Multi-Recorder Optisches Laufwerk: DVD Multi Speicherkarten-...
  • Seite 15: Störungsbehebung

    Störungsbehebung und Einschalten des Geräts ermittelt werden können, kann der Benut- Störungsbehebung zer eine oder mehrere der folgenden Maßnahmen durchführen, um zu versuchen, diese Störungen zu beheben: Störung Mögliche Abhilfe • Installieren und bedienen Sie den Server so, dass er nicht so viel Ursache elektromagnetische Energie abstrahlt, dass diese bei Geräten in der Nähe Störungen hervorrufen würde.
  • Seite 16 Logging on in the configuration tool....22 MEG6910-0018 Shutting down the server ......23 Remote control .
  • Seite 17: Scope Of Delivery

    Scope of delivery Scope of delivery For your safety – Uniq Server Basic DANGER ¼ – AC adapter and mains cable Risk of fatal injury from electric shock. – DVI VGA adapter All work on the device should only be carried out by –...
  • Seite 18: Getting To Know Uniq Server Basic

    Getting to know Uniq Server Basic System design and architecture Getting to know Uniq Server Basic A single server can control 40 Uniq devices at maximum, one Uniq Server Basic (hereafter referred to as the server) is an in- of which must be either tegral part of the Uniq system and controls and visualises –...
  • Seite 19: Connections, Displays And Operating Elements

    Connections, displays and operating elements Connections, displays and operating elements Front On/Off switch, green light 2 x USB 2.0 interfaces For connection of USB devices, such as a keyboard or a mouse. 4-in-1 memory card slot for: SD memory card, Memory Stick/Pro, multimedia card EJECT Eject button for DVDs...
  • Seite 20: Rear

    Connections, displays and operating elements Rear HDMI Connection for, e.g., television with HDMI input DVI-I Connection for a TFT monitor: you can use the DVI- VGA adapter to install a monitor with a VGA con- nection. Mains input, DC 19 V Connection for AC adapter (scope of supply) LAN connection, Ethernet RJ-45, Internal network for all Uniq components...
  • Seite 21: Installing The Server

    Installing the server Installing the server Operating environment The ambient temperature for operation is between -5°C and +40°C. CAUTION ½ The server can be damaged by excessive heat. • Set up the server in a well-ventilated, air-conditioned room. • Always keep the fans and fan slits free of obstructions so that air can circulate.
  • Seite 22: Starting Up The Server

    Starting up the server A/V Wizard Starting up the server 7 Follow the instructions from the A/V Wizard to optimise the audio and video settings of your connected monitor. CAUTION ½ The server may become damaged. Operation Protect the server from damage caused by voltage surg- AV Setup Confirm your entries with <OK>...
  • Seite 23: Checking The Settings

    Starting up the server Testing the monitor resolution Setting the volume AV Setup AV Setup The new setting will appear for You are listening to music. Step 2 Step 5 Step 1 Step 3 Step 4 Step 5 Final Step 1 Step 2 Step 3 Step 4...
  • Seite 24: Starting Up The Server With A Pc/Laptop

    Logging on in the configuration tool Starting the configuration tool Calling up the Uniq Interface 8 On the Uniq Interface homepage, select: 7 Start the browser: <Internet>  <SYSTEM ADMIN> http://192.168.80.1/uniq-admin/weborbiter.php Starting up the server with a PC/laptop Starting the configuration tool 1 Optional: Connect USB 2.0 Fast Ethernet Adapter to a 8 Start the browser: http://192.168.80.1 USB interface.
  • Seite 25: Shutting Down The Server

    Shutting down the server Shutting down the server Remote control You can use the remote control to control Uniq Interface. WARNING ¼ In order to ensure proper functioning of the remote control, en- Risk of injury! sure the following: To prevent injuries from electric shocks or damage to the •...
  • Seite 26: Operating Elements

    Remote control Operating elements Switch the device off Playback of a media file Open home page Sets the playback to pause Set the volume Stops the playback Scroll within lists Fast forward and rewind Play back the previous and next Switch volume on and off media file Start music tracks...
  • Seite 27: Technical Data

    Technical data Connections, displays and operating elements Technical data Front: 2 x USB 2.0 interfaces On/Off switch, green light System 4-in-1 memory card slot: SD memory Processor type: Intel® Core™ i3 card, Memory Stick/Pro, multimedia Main memory: 2 GB SO-DIMM DDR3 card Hard disk: 1x SSD 64 GB...
  • Seite 28: Troubleshooting

    Troubleshooting couraged to try to correct the interference by one or more of the follow- Troubleshooting ing measures: • Install and operate the server in such a manner that it does not radi- Fault Possible Solution ate sufficient electromagnetic energy to cause interference in near- cause by devices.
