CLEAR PRO SOFT
QUICKSTART
Plug the mains adapter into the rear panel to ensure the power
supply and to start the display-based start-up.
The welcome dialog appears on the display. Tap the display with your fi nger and select your prefered language. Confi rm or tap on
An installati on checklist is displayed, asking for the 4 most important steps of the installati on.
1
2
[D]
[B]
[A]
.
Mount the installati on fl ange onto the already installed CLEAR
installati on fl ange.
Please note the fl ow directi on. It is marked by an arrow on the
housing.
Connect the armored hose to the installati on
fl ange (armored hose raw water [A] and armored
hose soft water [B] at the outlet) and fasten the
hose with the clamps.
Connect the armored hose to the housing of the
bypass on the rear side (armored hose raw water
[C]
[C] at the inlet and armored hose soft water [D]
at the outlet) and fasten the hose with the
clamps.
conel.de
3
4
Detailed informati on on installing and ope-
rati ng the CLEAR PRO SOFT can be found
in the operati ng instructi ons.
Scan the QR code to download the opera-
ti ng instructi ons.
CONEL
DER BESTE FREUND DES INSTALLATEURS.
Schnellstart CLEAR PRO SOFT/1.0/11-23/©
CONEL GmbH / Margot-Kalinke-Straße 9 / 80929 München
Sämtliche Bild-, Produkt-, Maß- und Ausführungsangaben entsprechen
dem Tag der Drucklegung.
Technische Änderungen vorbehalten. Modell- und Produktansprüche
können nicht geltend gemacht werden.
Connect the fl ushing and overfl ow hose separately from each other to
the 3-fold funnel siphon (included in delivery) according to the standards.
The rinsing hose is black.
The overfl ow hose is transparent.
Fill regenerati ng salt tablets according to DIN EN
973 type A into the salt container.
