Separating the work lights
2
To separate the work lights joined together, proceed in the opposite direction of joining as
described above.
7.3 Autonomous use
1. Pressing the on/off switch (4) once (see Fig. a) turns the work lights (1) on. The lights are
now working in the brightest mode (100%).
2. Pressing the on/off switch a second time causes the lights to work with lower light intensity
(50% mode).
3. Pressing the on/off switch a third time turns the work light off.
4. With the batteries fully charged, the work light can last for about 2 hours.

7.4 Additional functions

The illumination direction of the work light (1) is infinitely adjustable from 0-90° by turning the
light bar (2).
Each light also features a built-in hook (Fig. c, (8)) for hanging the light.
Important:
When not used to hang the light, fold the hook back to prevent any objects from acciden-
tally getting caught on it. Never use the hook to hang any other objects. The hook should
only be used to hang the light.
The base (Fig. d, (12)) can be used as a stand. The light can be securely locked in place with
seven snap-in points.
The swivelling part in the base of the handle (Fig. e, (11)) has a built-in magnet that enables
each of the two lights to be attached to magnetic surfaces.
8 Troubleshooting
Problem Cause
The light does not turn on. The battery is empty.
When joined together, only The two lights are joined
one light turns on after incorrectly (arrows are not
pressing the on/off switch. aligned).
One of the lights is not
sufficiently charged.
Fig. b
Fig. c
Fig. d
Fig. e
Remedy
Charge the batteries (for 4-5
hours).
Join the lights together
correctly and fully charge
them.
When joined together, only The two lights are joined
one light is charging after incorrectly (arrows are not
connecting the charging aligned).
adaptor.
The light only comes on The batteries are discharged
briefly and then goes out. or the battery life has been
exceeded.

9 Cleaning and care

Important:
– Do not use aggressive cleaning agents, rubbing alcohol or other chemical solutions.
They can damage the housing and can cause the product to malfunction.
– Do not submerge the product in water.
1. Disconnect the product from the power supply.
2. Clean the product with a dry, lint-free cloth.
10 Disposal
This symbol must appear on any electrical and electronic equipment placed on the
EU market. This symbol indicates that this device should not be disposed of as
unsorted municipal waste at the end of its service life.
Owners of WEEE (Waste from Electrical and Electronic Equipment) shall dispose
of it separately from unsorted municipal waste. Spent batteries and accumulators,
which are not enclosed by the WEEE, as well as lamps that can be removed from
the WEEE in a non-destructive manner, must be removed by end users from the
WEEE in a non-destructive manner before it is handed over to a collection point.
Distributors of electrical and electronic equipment are legally obliged to provide free take-back
of waste. Conrad provides the following return options free of charge (more details on our
website):
in our Conrad offices
at the Conrad collection points
at the collection points of public waste management authorities or the collection points set
up by manufacturers or distributors within the meaning of the ElektroG
End users are responsible for deleting personal data from the WEEE to be disposed of.
It should be noted that different obligations about the return or recycling of WEEE may apply in
countries outside of Germany.

11 Technical data

Input voltage/current ..........................85 – 265 V/AC, 50 Hz
Power consumption ...........................max. 20 W
Luminous flux, single light .................100%: max. 600 lm per light
...........................................................50%: max. 300 lm per light
Luminous flux, both lights ..................100%: max. 1000 lm
...........................................................50%: max. 460 lm
Charging adaptor ...............................input 100 – 240 V/AC, 50 – 60 Hz,
...........................................................output 5 V DC, 1000 mA USB-A,
...........................................................USB-A to USB-C cable
Protection class .................................IP20
Battery type .......................................3.7 V; 2000 mAh 18650 Li-ion rechargeable battery
Light angle .........................................110°
Charging time ....................................4-5 hours
Battery runtime ..................................approx. 2 hours at 100% brightness
Operating temperature ......................-10 to +40 °C, 20-80% RH (non-condensing)
Storage temperature ..........................-20 to +45 °C, 20-80% RH (non-condensing)
Dimensions when joined together .....1020 x 64 x 64 mm (L x W x H)
Weight ...............................................707 g
This is a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau (www.conrad.com).
All rights including translation reserved. Reproduction by any method, e.g. photocopy, microfilming, or the capture in
electronic data processing systems require the prior written approval by the editor. Reprinting, also in part, is prohibited.
This publication represent the technical status at the time of printing.
Copyright 2024 by Conrad Electronic SE.
Join the lights together
correctly.
Charge the batteries for 4-5
hours. If the light still lasts
for a very short time, you
must replace the whole light
as the original batteries are
non-replaceable.
