F R O N T PA N E L
1. Power button
2. Power LED
3. SSD LED
4. WiFi LED
5. USB 3.2 port
6. Analog audio jack (3.5mm)
R E A R PA N E L
1. Power input (DC19V)
2. USB 2.0 port
3. HDMI port
4. DisplayPort
5. USB 3.2 port
6. USB 3.2 Type-C port
7. LAN (RJ45) port
8. WiFi antenna connector
S E T T I N G U P YO U R ZOTAC Z B OX N A N O
1. Connecting USB 2.0 devices
2. Connecting an HDMI display
3. Connecting a DisplayPort display
4. Connecting USB 3.2 devices
5. Connecting USB 3.2 Type-C devices
6. Connecting to a wired home network
7. Connecting antenna for Wi-Fi
8. Connecting the power adapter and turning on
the system
5
1
2 3 4
4
7
5
2
1
4
5
3
6
3
6
4
1
8
4
2
3
5
8
1
2
4
3
5
6
8
7
7
6
3
