AVLink INS201 Installationsanleitung Seite 2

STEP4
EN Hang the TV onto the wall plate AR
Mettere la televisore nella parete delle mura
FR IT
Accrochez le téléviseur sur la plaque murale
Hängen Sie den TV an die Wand-Platte テ レ ビ をパ ネ ルと 装着 の こ と
GE JP
Соединить с настенной панелью
SP Cuelgue el televisor en la placa de pared RU
Pendura a TV na chapa de parede 将 电视 挂 到墙 面 板上
PT CH
Solution 1
Before attaching the TV to the wall plate, tighten the top screw
nut to avoid the TV sliding off during installation.
TV plate
F1
Wall plate
Tighten the screw nut
STEP5
Cable
Cable management clip
Cable routing access points
Solution 2
Please use locking nuts and washers (F2) in place of thumbscrews (F1)
to secure the bracket more firmly
TV plate
Wall plate
±90°
±90°
-5°~10°
±3°
F2
Errors and omissions excepted.
Copyright© 2024 AVSL Group Ltd, Unit 2 Bridgewater Park, AVSL (Europe) Ltd, Unit 3D North Point House,
Taylor Road, Trafford Park, Manchester. M41 7JQ. North Point Bus. Park, New Mallow Road, Cork, Ireland
129.514UK User Manual
