SMOK RPM80 Kit Kurzanleitung

Single External 18650 Battery
Built-in 3000mAh
General safety information
• This leaflet contains important safety information. Please read this leaflet
carefully before using the product. Inappropriate use or handling of this
product may be harmful.
• This product is only intended to be used as an e-cigarette, for the consumption
of certain e-liquids. Do not use this product for any other purpose. This
product is not designed to be a smoking cessation device.
• To use this product, e-liquid must be inserted into the pod – as explained
below. ONLY E-LIQUIDS WHICH COMPLY WITH EUROPEAN UNION LAW, AND
OTHER RELEVANT LAW, SHOULD BE USED IN THIS PRODUCT. Consult a
reputable e-cigarette and e-liquid dealer for advice on what e-liquids can be
used in this product.
• Before using this product, please read carefully any information and
instructions for safe use relating to the e-liquid which is vaped using this
product.
• The SMOK product must not be offered for sale outside of, independently or
separately to, the box or this leaflet.
Instructions for safe use
• Handle this product with care at all times:
- Avoid damage to the product's internal and external components.
- Keep this product dry at all times. Do not immerse product in water as the
product is not waterproof.
- If you drop this product, make sure:
(1) the product is not broken, cracked or smashed;
(2) there is no leaking or leakage of e-liquid;
(3) components are not loose and have not come apart;
(4) the product functions normally and as intended;
(5) there is no damage to the mouthpiece. Clean the product particularly the
mouthpiece. Where necessary, take the product for a service to a reputable
e-cigarette dealer with the guarantee.
- Do not attempt to repair the product by yourself as damage or personal injury
may occur.
- Follow storage instructions (below).
- Do not overcharge the batteries. If the batteries overheat do not use this
product.
- Please download and install IVPS Tour APP.
- Please refer to:
https://www.smoktech.com/new-anti-counterfeiting-system,
and then follow the steps described in THE NEW
ANTI-COUNTERFEITING SYSTEM to verify your product.
- Only the verified product can get warranty service.
- If you have any questions, please contact SMOK via e-mail, phone or our
website to get more help.
• Before using this product, please read this leaflet, in full, carefully.
• Before using this product for the first time, ensure the product contains all
relevant parts and components:
RPM80 (Built-in 3000mAh)
The Kit Includes
EU Standard Edition
• 1 x RPM80 Device (3000mAh)
• 1 x RPM80 RPM Pod (RPM Mesh 0.4Ω Coil Preinstalled) (5ml)
• 1 x RPM80 RGC Pod (RGC Conical Mesh 0.17Ω Coil
Powered by nexMesh Preinstalled) (5ml)
• 1 x USB Cable
• 1 x User Manual
* You can also buy the RPM80 RGC RBA coil (Sold Separately) for more DIY fun.
EU 2ml Edition
• 1 x RPM80 Device (3000mAh)
• 1 x RPM80 RPM Pod (RPM Mesh 0.4Ω Coil Preinstalled) (2ml)
• 1 x RPM80 RGC Pod (RGC Conical Mesh 0.17Ω Coil Powered by nexMesh
Preinstalled) (2ml)
• 1 x USB Cable
• 1 x User Manual
* You can also buy the RPM80 RGC RBA coil (Sold Separately) for more DIY fun.
RPM80 Pro (Single External 18650 Battery)
The Kit Includes
EU Standard Edition
How to use this product:
1.Power On:
While the device is off, fast press Fire Key 5 times in 2 seconds to turn it on. The
screen successively displays "SMOK" and the product logo;
2. Vaping:
While the device is on, press Fire Key to vape (it will be forced to stop working
when vaping is longer than 8 seconds (RPM80) / 10 seconds (RPM80 Pro),
release and press again to vape again);
Quickly press the Fire Key 3 times to lock or unlock the vaping function.
3. Screen Unlocked Status:
(1) Press UP or DOWN Button to choose your desired wattage;
(2) Press UP and DOWN Button simultaneously to lock or unlock the wattage
adjustment function;
(3) Press the Fire Key and DOWN Button simultaneously to clear puff number;
(4) Press the Fire Key and UP Button simultaneously to choose theme color.
4.Power Off:
While the device is on, fast press the Fire Key 5 times in 2 seconds to turn it off.
- Before Vaping
- Fill the pod completely with e-liquid.
- Take 2-3 puffs while the power is off and without pressing the Fire Key.
- Begin vaping.
- If e-liquid is sucked through the SMOK product into the mouth, immediately
wash your mouth out completely, seek medical assistance if needed, then
remove the atomizer and clean the spillage before vaping again.
Instructions on how to fill this product with e-liquid
• Before the e-liquid in a SMOK product runs out, add e-liquid into the pod. This
should be done before the e-liquid runs out to avoid burning the coil.
• For instructions on refilling the SMOK product with e-liquid, users should refer
to these instructions below, and the instructions for bottles containing e-liquid.
• Users should first ensure that the nozzle attached to an e-liquid bottle can
easily connect – and slot into – the SMOK pod. The nozzle attached to an
e-liquid bottle must be smaller in diameter than the opening (filling slot) in the
SMOK pod. The opening (filling slot) of the SMOK product is below. The nozzle
of an e-liquid bottle must be smaller than the diameter measurements below.
- Before filling or refilling the SMOK pod, please read carefully these instructions
below. Please also read carefully the filling instructions provided with the
e-liquid which you vape.
- Before filling the SMOK product with e-liquid: first check that the nozzle on the
e-liquid container is securely attached to the e-liquid container itself, and that
the nozzle is at least 9mm long.
- Then check that the nozzle attached to an e-liquid refill container can easily
connect – and slot into – the SMOK pod. The nozzle attached to an e-liquid refill
container must be narrower, and smaller in diameter, than the opening in the
SMOK pod.
- Carefully connect the nozzle attached to an e-liquid refill container, into the
opening (i.e. filling slot) of the SMOK pod.
- Ensure that the nozzle of the e-liquid refill container is fully inserted into the
filling slot of the SMOK pod, and that there is no release of e-liquid until the
nozzle is fully inserted into the filling slot by refraining from touching the release
mechanism of the e-liquid refill container (see instructions for the container
containing e-liquid) until the nozzle is fully inserted into the SMOK pod.
- Once the nozzle is fully and securely inserted, and the docking system is
therefore fully connected, release e-liquid from the e-liquid refill container (see
instructions for the e-liquid refill container). Release of e-liquid from the e-liquid
refill container should be slow, careful and monitored by users to ensure
absolutely no spillage is possible.
- Filling and refilling should be carried out, outside the reach of children.
- Filling and refilling should be carried out in calm, stable surroundings. Refilling
should not be carried out in cars, trains, planes, boats while moving, or other
places which may result in spillage.
- In the case of spillage during filling or refilling, please immediately:
(1) Secure and close the SMOK pod and the e-liquid refill container;
(2) Keep those products outside the reach of children, pets and animals;
(3) Immediately clean spillage by wiping and collecting spillage in a dry paper
towel and disposing of that towel well outside of the reach of children, pets
and animals;
(4) Clean spillage area with disinfectant or other house-hold cleaning products.
Gloves or other personal protective equipment should be used to clean
spillage when necessary. Wash hands thoroughly after handling. Spillages
should be cleaned-up as soon as possible.
• In case of not using the device for extended periods, turn it off and take out
the battery if it is a removable battery product (turn off the MOD in cases of
built-in battery cells), seal off the battery, mod and atomizer and store them
separately.
• Do not place this product in the outdoor or in car under strong sunlight as
overheating and circuit damage may occur hence cause fire danger because of
the high temperature.
Instructions regarding charging
• Do not charge this product in hot, cold, damp environment or under direct
sunlight as short circuit may occur.
• Do not charge this product near fire, hot stove or combustible or explosive
materials or gas.
• Do not use a battery charger higher than 5V. Please use the original charging
line and reputable charger.
• Please unplug the USB cable within 2 hours after battery is fully charged to
extend the life of the battery.
Instructions on servicing and disposal
• This product should be serviced every 6 months by a reputable e-cigarette
dealer. Please retain a copy of your guarantee and provide dealers with the
guarantee for servicing.
• If this product fails a service, is broken, or otherwise malfunctions: do not use
this product, and dispose of this product appropriately.
• For disposal – Do not discard or dispose this product in general waste cabin,
please follow the local law and regulations on battery recycling and disposal.
Warnings regarding children
• KEEP THIS PRODUCT OUT OF REACH OF CHILDREN.
• This product is intended to contain nicotine containing-e-liquid.
NICOTINE CONTAINING E-LIQUID IS DANGEROUS. CHILDREN
MUST NOT GAIN ACCESS TO E-LIQUIDS.
• This product contains small parts which may pose a choking
hazard to children.
• The consumption of e-liquids is not suitable for those who are hypersensitive to
nicotine or any other relevant ingredient contained in an e-liquid (see e-liquid
ingredients for further details).
• E-liquids may contain allergens. Users should not consume e-liquids, and should
not use this product, if they have an allergy to any of the ingredients in an
e-liquid (see e-liquid ingredients for further details).
• E-liquids may contain skin sensitizers, or substances with the potential to cause
skin sensitization. Users should not consume or use e-liquids, and should not
use this product, if they have a contact sensitization-type allergic reaction to any
ingredients in an e-liquid (see e-liquid ingredients for further details).
• The consumption of e-liquids is not recommended for people suffering from
liver or kidney problems or for people suffering from long term throat disease.
• This product should not be used by pregnant or breastfeeding women without
seeking advice from a doctor or health care professional.
Contra-indications
• You should consult your doctor or another health care professional before
using this product if:
- You have heart disease (such as a previous heart attack, stroke, or disorders
affecting heart rate and rhythm).
- You have respiratory problems (such as emphysema, asthma, bronchitis or
other diseases that affect your respiratory tract).
- You have an overactive thyroid gland (or other disease that affects the thyroid,
or if you have adrenal or thyroid gland disorders).
- You have diabetes (use of nicotine may require changes to your medication,
and more careful monitoring of blood sugar levels).
- You are pregnant or breastfeeding (Nicotine is able to cross the placental
barrier, and presents risk to the unborn child. Nicotine use in pregnancy should
be minimised or avoided altogether. Nicotine can be excreted in breast milk).
- You have CVD, renal or hepatic impairment, lung disorders or lung conditions.
- You have stomach or duodenal ulcers.
Smoking and to a lesser extent nicotine may affect the uptake of certain
medications.
information below).
• If you experience significant nausea or changes in heart rate, seek immediate
medical attention. If a child comes into contact with or swallows an e-liquid, you
should contact your local hospital's accident and emergency department
immediately.
Addictiveness and toxicity
• Nicotine is a highly addictive substance, it is not recommended to be used by
young people, non-smokers and those who are not already vaping. Once you
have started using nicotine, you may find it hard to stop. Most people
experience little benefit from the use of nicotine, so it is better never to start.
• Although the levels experienced during the use of this product should not be
dangerous, if you suffer persistently from any side effects, or experience
significant changes to breathing or heart rate, you should consult your doctor.
• Nicotine is toxic if ingested (swallowed).
• Nicotine-containing products should be stored out of the sight and reach of
children (and pets and animals).
Ingredients
This product does not contain an e-liquid when sold to the consumer. For a
list of ingredients of the e-liquid – see e-liquid information.
Indication for delivery per dose
This product has been designed and manufactured to deliver nicotine doses
at consistent levels during normal conditions of use, over the course of the
expected lifetime of the SMOK product. Nicotine delivery per dose will
depend on the e-liquid used. For e-liquid containing 3mg/mL of nicotine:
approximately 105 ug/10 puffs; For e-liquid containing 6mg/mL:
approximately 216 ug/10 puffs; For e-liquid containing 12 mg/mL:
approximately 408 ug/10 puffs. This is an indication and estimate only.
English / 01
English / 03
English / 05
English / 07
English / 09
English / 11
English / 13
- Do not place the product in a hot or humid environment.
- Do not expose your product to hot, cold, damp or direct sunlight.
- KEEP THIS PRODUCT OUT OF REACH OF CHILDREN.
• DO NOT use this product if:
- broken, leaking, if parts are cracked or deformed, or if the product has
malfunctioned.
- abnormal heat occurs during vaping or charging. Do not overcharge the
batteries.
- there is concerning leakage of e-liquid from the pod.
- there is any perceptible change in flavor of the e-liquid.
- where microbial contamination or other contamination is suspected.
- the pod is empty or almost empty. E-liquid should always be in the pod to avoid
dry heating and burning the coil.
- THIS PRODUCT SHOULD BE SERVICED EVERY 6 MONTHS. If the product fails a
service, do not use. Defective items and parts must be replaced before re-use.
• General use:
- Do not eat, drink, or smoke while using this product.
- Use this product in moderation and in accordance with the instructions of use.
- Vaping products, including this product, should not be used in prohibited or
restricted areas.
- Vaping products, including this product, should not be used in high oxygen
environments.
- We recommend that you do not use vaping products, including this product,
while driving.
- Using electronic cigarettes may create undesirable effects to you and the people
around you.
Instructions on how to use this product for the first time
• Before purchasing the product, please verify that the product is an authentic
SMOK product. Fake and counterfeit products may be harmful to personal health.
To verify the product, please use our new AB product verification code system.
Note: Please carefully keep the AB verification codes on the package. AB
verification codes are required and will be used in product verification and
after-sales service.
English / 02
• 1 x RPM80 Pro Device
• 1 x RPM80 RPM Pod (RPM Mesh 0.4Ω Coil Preinstalled) (5ml)
• 1 x RPM80 RGC Pod (RGC Conical Mesh 0.17Ω Coil Powered by nexMesh
Preinstalled) (5ml)
• 1 x USB Cable
• 1 x User Manual
* You can also buy the RPM80 RGC RBA coil (Sold Separately) for more DIY fun.
EU 2ml Edition
• 1 x RPM80 Pro Device
• 1 x RPM80 RPM Pod (RPM Mesh 0.4Ω Coil Preinstalled) (2ml)
• 1 x RPM80 RGC Pod (RGC Conical Mesh 0.17Ω Coil Powered by nexMesh
Preinstalled) (2ml)
• 1 x USB Cable
• 1 x User Manual
* You can also buy the RPM80 RGC RBA coil (Sold Separately) for more DIY fun.
Components
The figure below is based on the RPM80 Pro.
Coil Head
Airflow System
18650
Battery
Battery Cap
The illustration is for reference only,
please refer to the specific item.
English / 04
Size of the filling slot of the pod
RPM80 RPM Pod / RPM80 RGC Pod
This product doesn't include e-liquids, or containers containing
eliquids. E-liquids must be bought separately – and then inserted
into these products. When filling or refilling a SMOK pod, please
check that the nozzle attached to an e-liquid container:
- is securely attached to the e-liquid container itself.
- the nozzle is no less than 9mm long.
- that the nozzle size is narrower than the filling slot of the
SMOK pod to avoid the risk of dermal contact and accidental
ingestion of e-liquid.
Filling Instructions
Please use a securely
attached nozzle no less than
9mm long when refilling
e-liquid
English / 06
Instructions on the coil
• After dripping e-liquid into a pod with a new coil, please let the pod stand for
15 minutes to avoid the possibility of coil-burning.
• Replace coil head.
Pull out the pod and old coil and then install a new one in the pod.
Install
Instructions for storage
• Store:
- Out of reach of children.
- Locked up.
- Separate and away from food and drink.
- Separate and away from medical products and medication.
- Well away from pets and animals.
- In the upright position, and secured to prevent falling over and leakage.
- Store in a dark and well-ventilated place below 30℃.
• Do not store for long periods containing an e-liquid. If the product is not going
to be used for a 2-3 days period: remove the pod and pour out the inside
e-liquid to avoid e-liquid penetrating into the product and shortening the
product's life-expectancy. To clean the inside atomizer, go to a dealer. Do not
clean the atomizer by yourself.
English / 08
Health Warning
The health warning below applies when the product is used as designed and
charged / filled with nicotine-containing liquid.
This product contains nicotine which is a highly
addictive substance.
It is not recommended for use by young people and
non-smokers.
• This product is suitable only for persons of 18 years or older.
• This product is not recommended for women that are pregnant
or breastfeeding.
Recommendation regarding young people and
non-smokers
This product is not recommended for use by young people and non-smokers.
Contra-indications for vulnerable groups
• This product is not suitable for:
- Persons of below 18 years of age.
- Persons who are ill or have certain medical conditions.
- Persons taking certain medication.
- Persons with certain allergies.
• This product is not recommended for use by:
- Young people and non-smokers.
- Women that are pregnant or breastfeeding.
• The consumption of e-liquids is not recommended for people suffering from
heart disease, high blood pressure, diabetes or those taking medication for
depression or asthma.
English / 10
Before you switch to a non-smoked nicotine source, you may need to talk to
your doctor about the need to adjust dosage of some drugs. (These include,
but are not limited to, clozapine, heparin, propranolol, ropinirole, and
theophylline).
Possible adverse effects
• While vaping, users may experience possible adverse effects. To avoid adverse
effects, it is recommended to use the e-liquid with lower nicotine content or no
nicotine. Adverse effects may include:
- Irritation of the mouth and throat
- Cough
- Dizziness
- Nausea/vomiting
- Hiccoughs/hiccups
- Chest palpitations
- Headache
- Dizziness
- Feeling lightheaded or faint
- Abnormal heart ratel
- Stomach discomfort
- Nasal congestion
•If you experience any of the above symptoms, or other adverse effects, stop
using the product immediately, seek medical attention, and provide the medical
expert with the label and leaflet of the e-liquid. Do not drive, and do not
operate machinery or engage in similar activities.
• If e-liquid is swallowed – refer to the instructions of the e-liquid product –
immediately seeking medical assistance when necessary (see Poison centre
information below).
• If e-liquid is splashed onto skin or in the mouth – wash skin and mouth
thoroughly with cold water – refer to the instructions of the e-liquid product –
immediately seeking medical assistance when necessary (see Poison centre
English /12
Medical Contact and Poison Center Information
• For emergencies – including ingestion or swallowing of e-liquid – seek
immediate medical help at your local hospital's Accident and Emergency
Department or phone 999.
• Otherwise, for medical advice or information you should contact your GP or NHS
111 (or NHS 24 in Scotland) on 111 (for 24 hour health advice).
• The National Poisons Information Service in the United Kingdom is unable to
provide clinical advice to members of the public.
Complaints and adverse events
Please report complaints or adverse events to:
Shenzhen IVPS Technology Co., Ltd.
• Address: 101, Building #69, Liantang Industrial Area, Tangwei Community,
Fenghuang Subdistrict, Guangming District, Shenzhen, China
• Website: www.smoktech.com
• Email: support@smoktech.com
• Phone number: + 86 755 86347180
Contact details of manufacturer
Shenzhen IVPS Technology Co., Ltd.
• Address: 101, Building #69, Liantang Industrial Area, Tangwei Community,
Fenghuang Subdistrict, Guangming District, Shenzhen, China
• Website: www.smoktech.com
• Email: support@smoktech.com
• Phone number: + 86 755 86347180
Contact details of legal or natural person within the EU
• Manufacturer's EU Representative: IVPS Technology B.V
• Address: IVPS Technology B.V, Zekeringstraat 17 A, 1014BM Amsterdam,
Netherlands
• Website: www.smoktech.com
• Email: support@smoktech.com
• Phone number: 0036 1 6188870
English / 14
Drip Tip
Pod
Air Inlet
Fire Key
0.96'' TFT Display
UP/DOWN Button
USB Port
6mm
No less
than 9mm
Pull out
