Bauknecht B2I HKD526 A Kurzanleitung

Quick Guide
THANK YOU FOR BUYING A BAUKNECHT PRODUCT.
In order to receive a more complete assistance, please register
your appliance on: www.bauknecht.eu/register
Before using the appliance carefully read Safety Instructions
guide.
CONTROL PANEL
1. ON-OFF/Reset button with indicator light
2. Program selection button
3. Salt refill indicator light
4. Rinse Aid refill indicator light
5. Program number and delay time indicator
6. Tablet indicator light
FIRST TIME USE
FILLING THE SALT RESERVOIR
The use of salt prevents the formation of LIMESCALE on the dishes and on
the machine's functional components.
• It is mandatory that the salt reservoir never be empty.
• It is important to set the water hardness.
The salt reservoir is located in the lower part of the dishwasher and must be
filled when the SALT REFILL indicator light
1. Remove the lower rack and unscrew the reservoir cap
(anticlockwise).
2. Position the funnel (see figure) and fill the salt reservoir
right up to its edge (approximately 1 kg); it is not unu-
sual for a little water to leak out.
3. Only the first time you do this: fill the salt reservoir
with water.
4. Remove the funnel and wipe any salt residue away from the opening.
Make sure the cap is screwed on tightly, so that no detergent can get into
the container during the wash program (this could damage the water
softener beyond repair).
Whenever you need to add salt, it is mandatory to complete the proce-
dure before the beginning of the washing cycle to avoid corrosion.
FILLING THE RINSE AID DISPENSER
Rinse aid makes dish DRYING easier. The rinse aid
dispenser A should be filled when the RINSE AID
REFILL indicator light
D
NEVER pour the rinse aid directly into the
C
appliance tub.
A
PROGRAMS TABLE
Program
Eco 50°- Eco program is suitable to clean normally soiled tableware.
that for this use. it is the most efficient program in terms of its
1.
combined energy and water consumption. and that it is used to
assess compliance with the EU Ecodesign legislation.
-
Intensive 65°
2.
especially suitable for pans and saucepans (not to be used for
delicate items).
-
Mixed 55° Mixed soil. For normally soiled dishes with dried
3.
food residues.
Fast Wash&Dry 50° - Normally soiled crockery. Everyday cycle, that
4.
ensures optimal cleaning and drying performance in shorter time.
Rapid 28' 50°
5.
dishes with no dried food residues. Does not have drying phase.
-
Silent 50°
Suitable for night-time operation of the appliance.
6.
Ensures optimal cleaning and drying performance with the lowest
noise emission.
-
Hygiene 65°
7.
antibacterial wash. Can be used to perform maintenance of
the dishwasher.
Prewash - Use to refresh crockery planned to be washed later. No
8.
detergent to be used with this program.
Self-Clean 65° - Program to be used to perform maintenance of the
9.
dishwasher, to be carried out only when the dishwasher is EMPTY
using specific detergents designed for dishwasher maintenance.
7. Display
8. Half Load indicator lights
9. Half Load button
10. Delay button
11. START/Pause button with
indicator light / Tablet (Tab)
in the control panel is lit.
in the control panel is lit.
Programs description
Program recommended for heavily soiled crockery.
-
Program to be used for half load of lightly-soiled
Normally or heavily soiled crockery, with additional
PLEASE SCAN THE QR CODE ON YOUR
APPLIANCE IN ORDER TO HAVE MORE
DETAILED INFORMATION
1 2 3 4
FILLING THE DETERGENT DISPENSER
To open the detergent dispenser use the opening device C. Introduce the
detergent into the dry dispenser D only. Place the amount of detergent for
pre-washing directly inside the tub.
If all-in-one detergents are used, we recommend using the TABLET button,
because it adjusts the program so that the best washing and drying results
are always achieved.
Usage of detergent not designed for dishwashers may cause
malfunction or damage to the appliance.
WATER SOFTENING SYSTEM
Water softener automatically reduces water hardness, consequently pre-
venting scale buildup on heater, contributing also to better cleaning effi-
ciency. This system regenerates itself with salt, therefore it is required
to refill salt container when empty.
Frequency of regeneration depends on water hardness level setting - regen-
eration takes place once per 6 Eco cycles with water hardness level set to 3.
Regeneration process starts in final rinse and finishes in drying phase, be-
fore cycle ends.
• Single regeneration consumes: ~3.5L of water;
• Takes up to 5 additional minutes for the cycle;
• Consumes below 0.005kWh of energy.
Available
options
*)
-
-
-
5 6 7 8 9 10
Duration
Water
of wash
consumption consumption
program
(litres/cycle)
(h:min)
**)
3:35 9.5
2:40 18.0
2:15 16.0
1:30 11.5
0:28 9.0
3:35 16.6
2:00 12.0
0:12 4.7
0:50 10.0
EN
11
Energy
(kWh/cycle)
0.95
1.60
1.40
1.30
0.50
1.30
1.50
0.01
0.80
