Wickey Smart Noble Montageanleitung Seite 29

E29
A
1x
2400 x 88 x 88mm
D
2x
Single
4x
Quadruple
3x
Triple
1
10 mm
B
1x
E
1x
7 x 80mm
44 mm
M10 x 220mm
Cap
Option 1
A
D
Option 2
Option 3
C
1x
F
2x
Single
4x
Quadruple
3x
Triple
F
Wickey GmbH & Co.KG | Version 105
M10
Swing Hook
