Seite 2
Important Safety Instructions pro.Bose.com The symbols below are internationally accepted symbols that warn of potential hazards with electrical products. This symbol, wherever it appears, alerts you to the presence of un-insulated dangerous voltage inside the enclosure – voltage that may be sufficient to constitute a risk of shock.
Seite 4
Instrucciones de seguridad importantes pro.Bose.com Los siguientes son símbolos reconocidos internacionalmente que avisan de los riesgos potenciales de los productos eléctricos. Siempre que aparezca este símbolo, alerta sobre la presencia dentro del cuerpo del producto de fuentes de voltaje peligroso no aisladas, suficientes para provocar un riesgo de descarga.
Seite 5
Instrucciones de seguridad importantes pro.Bose.com 13. Cuando utilice un carrito, tenga cuidado al mover el carrito con el dispositivo para evitar que caiga y produzca daños. 14. Desenchufe el aparato si se produce una tormenta eléctrica o si no lo va a utilizar durante periodos prolongados de tiempo.
Seite 7
Instructions importantes relatives à la sécurité pro.Bose.com Les symboles internationaux ci-dessous vous avertissent des dangers potentiels inhérents aux appareils électriques. La présence de ce symbole vous met en garde contre une tension dangereuse non isolée à l’intérieur du boîtier. Celle-ci est suffisamment élevée pour présenter un risque d’électrocution.
Seite 9
Wichtige Sicherheitshinweise pro.Bose.com Sie unten aufgeführten Symbole sind international anerkannt und warnen vor möglichen Gefahren durch elektro- nische Produkte. Dieses Symbol warnt Sie vor einer nicht isolierten Spannung in einem Gehäuse, die hoch genug ist, um einen Stromschlag auszulösen. Dieses Symbol weist Sie auf wichtige Betriebs- und Wartungsanweisungen in der beiliegenden Dokumentation hin.
Seite 10
Wichtige Sicherheitshinweise pro.Bose.com 12. Verwenden Sie für das Gerät nur Rollwagen, Ständer, Dreibeine, Halterungen oder Tische, die vom Hersteller zugelassen sind oder zusammen mit dem Gerät verkauft werden. 13. Falls Sie einen Rollwagen verwenden, dürfen Sie die Einheit Gerät/Rollwagen nur mit Vorsicht bewegen, damit Verletzungen beim möglichen Umkippen ausgeschlossen sind.
Seite 12
Its size and I/O density make it easy to put Dante connectivity close to analog devices, helping to reduce costly and interference-prone analog wiring. Balanced audio inputs (2) Power/ ID LED Balanced audio outputs (2) Figure 1. ControlSpace WP22B-D wall plate front and back...
Seite 13
Note: The WP22B-D has a label on the front of the metal housing at the top that lists the last 6 digits of the MAC address. Important for initial device identification, these digits are part of the device's default network name when detected by Bose ControlSpace Designer ®...
Seite 14
WP22B-D Installation Guide pro.Bose.com Mounting A typical installation will involve mounting the wall plate into a 2-gang junction box or low-voltage ring. Before starting, make sure the wall box where the WP22B-D is to be installed is pre-wired with a suitable network cable back to a PoE enabled network switch or mid-span injector.
Seite 15
WP22B-D Installation Guide pro.Bose.com ardware OnneCtiOns The WP22B-D accepts and drives either unbalanced or balanced audio devices. Refer to the following diagrams and instructions for connecting different types of audio devices. Professional grade audio cabling is recommended to achieve the best audio performance throughout the system.
Seite 16
WP22B-D Installation Guide pro.Bose.com Input from an Unbalanced Source To connect a 2-wire unbalanced source to the WP22B-D, connect the positive output of the unbalanced source to the positive input of the WP22B-D. Connect both the source and WP22B-D input grounds together, and short the negative input of the WP22B-D to ground at the input of the WP22B-D.
Seite 17
WP22B-D Installation Guide pro.Bose.com Output to a Balanced Destination To connect to a balanced input on a destination device, connect the positive, negative and ground connections of both the WP22B-D output to the destination input respectively. Figure 5. WP22B-D Output...
Seite 18
WP22B-D Installation Guide pro.Bose.com eviCe OnfiguratiOn There are two parts of the device that require software to setup. First the audio routing, and second the configurable features of the device itself. Both should be carried out using ControlSpace Designer ™...
Seite 19
WP22B-D Installation Guide pro.Bose.com Software Application ® ™ ControlSpace Designer software v4.2 or later General A/D Converters 48 kHz, 24-bit System THD < 0.01 % at any gain, input signal 3 dB below maximum PoE Class Class 0 802.3af PoE PD compliant...
