Owner's manual
Remote control
2
1
4
7
11
10
EN
CONNECTION
• Connect the radio plug from the car to the ISO socket of the radio (adapters for different
car models are sold separately).
• A USB extension cable (sold separately) can be used for the rear USB charging socket and
take it out, for example, near the passenger seat.
22
1. Power button/change mode (press
3
and hold to turn off the radio)
2. Mute sound
6
3. Band change
5
4. Previous track
5. Next track
9
6. Clock button
8
7. Volume down
12
8. Volume up
9. Settings button
10. Program/function buttons
11. Automatic
scanning
stations (press and hold)
12. Graphic equalizer
• It is recommended to connect the external microphone (included in the kit) to the
microphone jack and bring it to the vicinity of the driver's seat. If the external microphone
is not connected, the built-in microphone in the radio will be used during the calls.
Socket B
1. Rear right speaker +
2. Rear right speaker —
3. Front right speaker +
4. Front right speaker —
5. Front left speaker +
6. Front left speaker —
7. Rear left speaker +
8. Rear left speaker —
of
radio
Owner's manual
Socket A
1. Unused
2. Unused
3. Unused
4. Power B+ - 12 V power supply
5. Audio antenna B+ - antenna power
6. Unused
7. ACC +12V — 12 V after ignition
8. GROUND - grounding
EN
23
