Cabinets & shelving COMBUS EN Assembly scheme | DE Aufbauanleitung | FR Schéma d'assemblage 00:20 Example of the combination. Specific combination (wide, height, storage components type) depends on order option and choosen components. Beispiel für eine Kombination. Die konkrete Kombination (Breite, Höhe, Art der Ablagen) hängt von der Wahl der...
Seite 2
Set of storage components depends on order option and choosen accessories. Instructions for other options provided with other packages. Das Set der Ablagen hängt von den Bestelloptionen und dem gewählten Zubehör ab. Die Anleitungen für andere Optionen liegen den jeweiligen Packungen bei.
Seite 3
Unlock the fitting (6 pcs.) Die Verbindungsstücke (6 Stück) lockern Débloquer les raccords (6 pcs.) Remove the top Oberseite abnehmen Retirer la partie supérieure M60EJ033...
Seite 5
For drawer installation at 1H level, check the a part of these instructions. Für die Montage des Schubfachs auf der Höhe 1H den Teil a diese Anleitung beachten. Pour l'installation d’un tiroir au niveau 1H, voir la partie a de ces instructions. 2 x2 M6x10 M42C0215...
Seite 6
3 x2 M6x35 M42C0016 For drawer installation at 2H level, check the b part of these instructions. Für die Montage des Schubfachs auf der Höhe 2H den Teil b diese Anleitung beachten. Pour l'installation d’un tiroir au niveau 2H, voir la partie b de ces instructions. M60EJ033...
Seite 8
Further steps applicable for both options. Die verbleibenden Schritte gelten für beide Optionen Étapes restantes applicables aux deux options. 5 x2 6 x2 M42Z0133 4.0x20 K M42A0020 7 x2 M42J0027 M60EJ033...
Seite 9
Place the top Oberseite aufsetzen Placer la partie supérieure Lock the fittings (6 pcs.) Die Verbindungsstücke (6 Stück) verriegeln Bloquer les raccords (6 pcs.) M60EJ033...
