Factory Reset
Troubleshooting? Don't know what's going on with the keyboard?
1. Try factory reset by pressing fn + J + Z (for 4 seconds)
2. Download the right firmware for your keyboard from our website. Remove the
power cable from the keyboard.
3. Remove the space bar keycap to find the reset button on the PCB.
4. Hold the reset key while plugging in the power cable and then release the reset
key. The keyboard now will enter DFU mode.
5. Flash the firmware with the QMK Toolbox.
6. Factory reset the keyboard again by pressing fn + J + Z (for 4 seconds)
Step by step guide can be found on our website.
V5 Customizable Keyboard Specifications
Layout
Switch type
Width
Length
Front height
Back height
Front height
Back height
Keyboard feet height
Angle
96%
Mechanical
142.3 MM
388.87 mm
18.85 mm (without keycaps)
26,43 mm (without keycaps)
28.54 mm (with OSA keycaps installed)
37.52 mm (with OSA keycaps installed)
2 mm
3.5 / 7.2 / 9.73 degree
9
