FLINQ FQC8215 Handbuch Seite 3

EN Manual
Motion detection Yes 20 sec ON after last motion
is detected
Detection motion range 3~5m
Detection angle 120°
Protect function yes, hardware & software
Kelvin 3000K
Lumen +/- 50 Lm max.
Power 1W
Color White
HQ LED's 5x SMD 2835 high power LED
Lifespan < 30.000 hours
Battery HP Li-Polymer battery 3.7V 600mAh
(non-replaceable type)
Dimensions 80x28 mm
Weight 27 gr.
Read and follow the instructions contained in this manual carefully. Keep
these instructions at a safe place for future reference. IP 20: Only for
indoor use. Never immerse this light under water. The operating life of
the product will be less if the ambient temperature is higher than 45°C or
lower than -10°C.
Install the light(s)
1 Charge the lights
via usb cable
Charge the lights via the USB
cable. The LED indicator light will
be red while charging and turns
green when fully charged.
2 Install metal
magnet plate
Use the metal plate with tape to
install it by the internal magnet.
The lamp can be put into any
metal surface without any extra
tools or parts needed.
Note: During the first use of the product first charge it at a minimum
time for 2-5 hours in the OFF position!
TIP: You can use the lamps continuously ON when needed with the USB
cable connected to any applicable adapter as mentioned above and with
the specifications mentioned. Note: Using the lamps like this will shorten
the battery use and lifecycle time of this device.
Maximum lighting time depends on battery time charging. Minimum
charging time is 90 min.
Select a location that is not located close to other light sources, such as for
example street lighting, because this enables the lamp to be switched off
automatically when set in AUTO setting. You can install the lamps with the
parts included to mount/place it on a solid wall, ceiling, table/desk or use the
tape/magnet applied. See below illustrations.
You can try other ways to install and use it depending on the actual
condition by using the hanger, tape, magnet or just put it anywhere you like
at any place you need to have some lights!
Note: When use the tape with metal plate choose the location wisely as
the tape is fixed very well and not easy to remove.
3 Turn on the light
via the button
Turn the light on or set light to
auto mode via the button on the
back of the light.
FlinQ Indoor Motion Lights
4 Place the lights on
the metal plate
Attached the motion lights to
the metal plate via the internal
magnet.
