LABYRINTH
01
HOLE PATTERN
200
Ø8,5
Ø40
CABLE ENTREE
09a
02b
07
06
04
03a
05
08
03b
09b
02a
INSTALLATION INSTRUCTIONS - PART A
01.
MAKE HOLE PATTERN
02.
OPEN THE DEVICE
03.
PLACE THE DEVICE
04.
MAKE THE ELECTRICAL CONNECTION
05.
UNSCREW LAMP TUBE
06.
PLACE LAMP
07.
PLACE SPRING ON LAMP
08.
FASTEN LAMP TUBE
09.
CLOSE THE DEVICE
10.
SWITCH ON
OFF
ON
04c
H07 V-U 1 - 2,5mm²
PUSH
220-240V
04
04c
04b
04c
LIGHT ® nv. BELGIUM
04d
04a
ACCESSORY SET
1x
1x
1x
last update : 05/01/2009
