IMPROTANT
Remove the stylus protector.
-
Be sure that the tone arm is being detached from the tone arm rest before operating and re-
-
secured again afterwards.
- Phono and Aux are sharing the same function band. Once the 3.5mm Aux-in jack is being
connected, unit will switch to Aux-in function automatically. Therefore, make sure the 3.5mm
Aux-in jack is not being connected if you wish to play a record.
PLAYING RECORDS
This system includes a 3-speed, belt-drive turntable. You can play 33, 45 and 78 rpm records.
1. Select the "PHONO/AUX" mode.
2. Make sure that you have removed the stylus cover from the stylus and have released the
tone arm lock that secured the tone arm to the tone arm rest.
3. Set the turntable speed selector to the appropriate speed 33 or 45 or 78 rpm. If you are
playing 45 rpm 'singles', place the 45 rpm adapter on the centre spindle.
4. Place your record on the centre spindle.
5. Lift the tone arm from the rest and slowly move it to the edge of the record. The turntable
starts automatically. Place the tone arm to the desired position of the record.
6. At the end of record, the platter will automatically stop rotating. Lift the tone arm from the
record and return it to the rest.
7. To stop manually, lift the tone arm from the record and return it to the rest.
Remark : As some kind of record the auto-stop area was out of the unit setting, so it will stop before
the last rack finish. In this case, select the auto-stop switch to " off " position, then it will run to the
end of the record but will not stop automatically (turn off the power button or switch back the "AUTO-
STOP ON/OFF" switch to " on " position to stop the platter rotate). Then put back the tone arm to
the rest position.
GENERAL OPERATION
STOP / EJ.(EJECT) KEY
FAST FORWARD KEY &
FAST REWIND KEY
PLAY KEY
PAUSE KEY
RECORD KEY Deck 1 only
TURNTABLE OPERATION

CASSETTE TAPE

Press this to stop all tape deck operation.
Press it again to open the cassette door.
Press these to start rapid tape winding - either in a forward or
reverse direction.
Press the Stop / Eject/Fast Rewind keys when the cassette spools
stop turning.
Press this key to start playing a cassette tape.
Press this key to temporarily stop the cassette tape operation.
Press it again to resume play.
Press this together with the play key to start tape recording.
