Cable Connection - Ender 3 V2 Neo Kurzanleitung

3.2 Installing display screen
A.
B.
C.
4

3.3 Cable Connection

A.
C.
D.
Caution
Please ensure the correct position for the power supply
switch and mains before supply connection, in order to
avoid damage to the device.
If the mains between 100V and 120V, please select the
115V for the power supply switch.
If the mains between 200V and 240V, please select the
230V for the power supply switch (default is 230V).
4 Leveling
X, E, Z-axis motor port
0.1mm
3
X-axis limit switch
A
B2
B1
B3
D
14
C
