Cudy WR2100 Benutzerhandbuch Seite 4

If your internet connection is through an Ethernet cable directly from the wall instead of
through NSL/Cable/Satellite modem, connect the Ethernet cable to the router's WAN
port and skip steps 1, 2 and 3.
Internet
Power Socket
Turn off the modem and remove
the battery if it has one.
Connect your computer to the router (wired or wireless).
Wired: Turn off the Wi-Fi on your computer and connect it to router's LAN port via an
ethernet cable.
Wireless: Connect your device to the router's Wi-Fi using the SSID (network name) and
Password printed on the bottom of the router.
Launch a web browser and enter
address bar. Use "admin" for password to log in.
Note: If the login windows does not appear, please refer to the FAQ.
Then the popup window will appear. Please follow step by step instructions to set up
the internet connections.
Note: If the popup windows does not appear, please click "Quick Setup" on the status
page.
You're successfully connected co the internet!
Turn on the modem and then wait about two
minutes for it to restart.
Modem
Connect router's internet port to
DSL/Cable Modem/Ethernet.
http://cudy.net/
4
or http://192.168.10.1/
Connect the power
adapter to the router,
and wait a minute until
the systém LED changes
from flashing light to
solid light (either red or
blue), which means that
the system startup is
completed.
in the
