Stroller frame parts(P1)
1.Handle grip
2.Adjustable handle button
3.Folding lever button
4.Handle tube
5.Main connector
6.Auto lock
7.Brake and release pedal
8.Rear wheel
9.Wheel cap
10.Rear leg tube
11.Front leg tube
12.Front wheel quick release button
13.Front wheel
14.Directional lock
15.Front wheel socket
16.Folding lever
17.Rear wheel quick release button
18.Stabilizing tube
19.Brake line tube
Seat unit parts(P2)
20.Front canopy frame
21.Back canopy frame
22.Canopy faucet
23.Canopy button
24.Safety bar button
25.Seat unit release catch
26.Seat unit base
27. Footrest adjustment buttons
28.Seat unit bottom
2 .
9 Backrest adjustment lever
.
30 Safety bar
3 .
1 Backrest adjustable belt
3 .
2 Backrest lever
3 .
3 Backrest regulating part
To open the stroller frame
The status when it's folded(P3).Release the folding hook as the picture shows(P4).Hold
the handles and lift upwards until the chassis is fully expanded(P5).The status when it's
unfolded(P6).
Front wheel assembly(P7)
