Installation
1
Fix the camera product you purchased using the screws attached to the
top of the case.
At this time, take careful note of the direction of the assembly bump.
Place the case bottom on the desired location and fix it.
2
You can use any of the 6 fixing screw holes you wish.
3
When laying the cable through the center of the back box, insert the
cable through the screen in the central section before fixing the case
bottom.
This product supports a single type, double type or octagon type gang
box.
Fix the case bottom firmly and hook the safety strap connected to the
4
top cover to the arrow-shaped clamp.
With the cable firmly hung, connect the cable.
After completing the cable connection, fasten the 3 screws that connect
5
the case top to the case bottom.
Using the PAN/TILT fixture, adjust the camera to face in direction you
want to monitor (refer to the camera manual).
Product Outline
Product Specifications
Weight : 320g
Ciężar : 320g
•
•
Material : ALUMINIUM
Materiał : ALUMINIUM
•
•
Operation temp. : -50°C~60°C
Temperatura robocza : -50°C~60°C
•
•
Operation hum. : 0~100%
Wilgotność robocza : 0~100%
•
•
Poids : 320g
•
Ağırlık : 320g
•
Matériau : ALUMINIUM
•
Malzeme : ALÜMİNYUM
•
Température de fonctionnement :
•
Çalışma sıcaklığı : -50°C~60°C
•
-50°C~60°C
Çalışma nem değeri : 0~100%
•
Humidité de fonctionnement : 0~100%
•
Gewicht : 320g
Hmotnost : 320g
•
•
Material : ALUMINIUM
Materiál : HLINÍK
•
•
Betriebstemperatur : -50°C~60°C
Provozní teplota : -50°C~60°C
•
•
Betriebsluftfeuchte : 0~100%
Provozní vlhkost : 0~100%
•
•
Peso : 320g
重量 : 320g
•
•
Material : ALUMINIO
材質 : アルミニウム
•
•
動作温度 : -50°C~60°C
Temp. funcionamiento : -50°C~60°C
•
•
Hum. funcionamiento. : 0~100%
動作湿度 : 0~100%
•
•
Peso : 320g
重量 : 320g
•
•
Materiale : ALLUMINIO
材料 : 铝质
•
•
Temperatura di esercizio : -50°C~60°C
工作温度 : -50°C~60°C
•
•
Umidità di esercizio : 0~100%
工作湿度 : 0~100%
•
•
무게 : 320g
•
Вес : 320g
•
재질 : 알루미늄
•
Материал : АЛЮМИНИЙ
•
사용 온도 : -50℃~60℃
•
Температура при работе : -50°C~60°C
•
사용 습도 : 0~100%
•
Влажность при работе : 0~100%
•
mm(inch)
PT01-004566A
