Princeton Tec SYNC Kurzanleitung

ENGLISH
Battery Installation - See Figure 1
3 AAA • Alkaline (LR03)
• Lithium (L92)
• Rechargeable NiCad or NiMH
Princeton Tec cares about the environment
and recommends recycling batteries. For
more information about battery recycling,
please go to www.batteryrecycling.com.
Install three AAA batteries according to the
polarity markings on the inside of the cabinet.
Observe proper battery polarity when install-
ing the batteries. Improper installation of the
batteries will damage the light and void the
warranty.
Rotate the door to the closed position,
squeeze the body between your forefin-
gers and thumb to snap the door latch over
the catch.
WARNING
Never mix fresh and used batteries.
• Never mix different battery brands or
chemistry types.
• Always remove drained batteries
immediately.
• Remove batteries during long periods
of storage. NOTE: Rechargeable NiCad
or NiMH batteries may result in reduced
brightness due to lower nominal voltage.
See Figure 2
Switch Operation -
Modes are selected by rotating the power
dial to the desired setting. The default "lock-
out" setting positions the dial indicator so it
is protected from accidental activation dur-
ing transport. One step forward activates red
Ultrabright mode. The next step forward is
the off position. Next comes Ultrabright low
flood mode. An additional step activates Ul-
trabright high flood mode.The next setting
provides the Maxbright spot beam. The final
step activates both spot and flood beams for
maximum output in the Dualbeam pattern.
Power Consumption
Refer to the burn time chart for performance
data for different battery types and mode set-
tings.
The times listed in this chart assume you start
with fresh batteries and use only one mode.
Figure 1 – Battery Replacement
1 2
Figure 2 – Switch Operation
5 MODES
DUAL BEAM
SPOT
HIGH FLOOD
LOW FLOOD
RED
DISTANCE
(METERS)
Princeton Tec calculates total burn time as the time it takes for the light source to produce a minimum of
•
0.25 lux at 2 meters. 0.25 lux is about the equivalent of a full moon on a clear night.
Princeton Tec berechnet die Gesamtbrenndauer bezogen auf eine von der Stirnlampe erzeugte minimale
•
Beleuchtungsstärke von 0,25 Lux in 2 Meter Abstand. 0,25 Lux entsprechen in etwa der Beleuch-
tungsstärke des Vollmonds in einer klaren Nacht.
Princeton Tec défi nit la durée totale d'éclairage comme le temps nécessaire à la source
•
lumineuse pour produire un minimum de 0,25 lux à 2 mètres. 0,25 lux équivaut à peu près à la
luminosité d'une pleine lune dans un ciel nocturne dégagé.
Troubleshooting
If the Sync fails to light:
• Check the batteries for proper installation.
• Replace batteries if proper installation is con-
firmed.
• Check the light for water contamination on
the circuit board.The light will resume normal
operation once the water is shaken or blown
out and the light is left open until completely
dry. If the light has been contaminated with
salt water, flush the unit with fresh water and
dry as described above.
USA– International 5-Year Warranty
WARRANTY – PrincetonTec warrants this prod-
uct to be free from defects in workmanship
and materials under normal use for 5 years.
This warranty covers all of the component
parts of the product except batteries. This war-
ranty does not cover deterioration due to nor-
mal wear or damage due to misuse, alteration,
negligence, accidents, or unauthorized repair.
Princeton Tec will repair or replace parts which
are defective in workmanship or materials.
Your authorized PrincetonTec Dealer and Princ-
eton Tec are the only facilities authorized to
repair the product. After (3) unsuccessful at-
tempts (within the warranty period) to repair
the product, you have the right to elect replace-
ment of the product or a refund of the purchase
price less allowance for use of the product. NO
INCIDENTAL OR CONSEQUENTIAL DAMAGES
Remplacement des piles
3
Modes de fonctionnement
TOTAL BURNTIME 75 H
100 H
150 H
200 H
0
6 24 32
ARE INCLUDED IN THIS WARRANTY. (Some
states do not allow the exclusion or limitation
of incidental or consequential damages, so
the above limitations or exclusions may not
apply to you.) This warranty gives you spe-
cific legal rights, and you may also have other
rights which vary from state to state.
Princeton Tec reserves the right to change
product specifications without notice.
Return Policy
If your light fails to operate, follow these sim-
ple steps:
1) Check batteries. Replace if necessary.
2) Contact Princeton Tec customer service at
800-257-9080 to request an RMA number
in order to send your light for repair or re-
placement. No warranties will be accepted
without an RMA number.
3) If the light continues to function im-
properly, return it without batteries to:
Princeton Tec, 5198 Rt. 130 Bordentown,
NJ 08505. Postage due and freight collect
items will not be accepted.
PrincetonTec
PO Box 8057 ,
Trenton, NJ 08650
Phone: 609-298-9331
Fax: 609-298-9601
Batteriewechsel
4
Schalterbetätigung
RED
OFF
BEAM DISTANCE
BEAM DISTANCE
58 m 56 m 22 m
100 H
52 m 48 m 26m
32 m 29 m 18 m
24 m 23 m 16 m
6 m 5 m 3 m
0 H 0.5 H 10 H
58
T= Time/ Zeit/ Temps
Time/ Time/ Temps Temps
www.princetontec.com
© 2014 PrincetonTec
