Avtek TS 7
EN
Easy
1. Connect the Display to the mains socket
Connect the Display to the mains socket that supplies 110-240 V AC, 50/60 Hz.
2. Insert the batteries into the remote
Remove the screw that secures the battery
compartment cover on the back side of the remote
control first. Remove the cover gently. Insert two size
AAA batteries. Observe the correct polarity (+/-) when
inserting batteries. Do not mix old and new batteries.
Replace only with same or equivalent type. Place the
cover back on. Then screw the cover back on again.
3. Turn On/Off the Display
If the Display has an On/Off switch, after connecting the Display to the mains set the main On/Off switch to the "1" position.
The Display will switch into standby mode. Press the Standby button on the remote or press the centre of the joystick in located
on the rear left side of the Display to switch it on from standby. Press the centre of the joystick in and hold it down for a few
seconds or press the Standby button on the remote to switch the Display into standby mode. To switch the Display off, set the
On/Off switch to the "2" position.
Front view
(*) The location of the On/Off button may differ depending on the model.
4. Connect other equipments to the Display
PLEASE ENSURE BOTH UNITS ARE SWITCHED OFF BEFORE CONNECTING.
Use the proper cable to connect two together. To select the desired input,
press the Source button on the remote control.
Each time it is pressed the on-screen menu confirms your selection.
EXAMPLE CONNECTIONS
Quick guide manual
2
1
Back view
HDMI connection
VGA connection
Standby
button
Joystick
3
Interactive flat panel
Remote
Source
button
Remote
RS232 connection
Ethernet connection
