WSB
Loudspeaker Wall Bracket
Instruction Manual
ENG
Read these instructions carefully before installing your equipment.
Install the wall bracket in a suitable location using fixings which are appropriate for the wall material and
structure. Consult a qualified builder if you are in any doubt as to the structural integrity of the wall.
Do not attempt to alter or modify any part of the wall mount or it's attachments.
Do not use if any parts are broken or appear to be damaged.
Tighten all bolts and fixings securely. Only use fixings provided with this bracket.
Do not mount your loudspeaker near to sources of heat or moisture.
Always have a minimum of two persons to install the wall bracket and loudspeaker.
Speaker Fixing Kit
A - 1.5mm Drill
B - 4mm x20mm Woodscrew
F - M5 x 10mm
(Pre-assembled)
Also required
1
1
Mount Bracket To Wall
x1
NOTE:
For ease of installation mount bracket on wall using
position 1 and mark other positions using a spirit level.
x4 Then remove fixing from position 1, remove bracket and
drill other positions
Use Fixings suitable for your type of wall construction.
Use All available fixing points
If in any doubt of the suitability of the wall, it's construction
x2
or what type of fixings to use, consult a qualified builder
or installer.
1
