- Seite 1 MB210 & MB210-WR Compact Subwoofers Installation Guide Guía de instalación Guide d’installation Installationsanleitung Guida all’installazione Installatiehandleiding...
- Seite 2 Do not attempt to service this product yourself. Refer all servicing to authorized service centers, disposal and recycling helps protect natural resources, human health and the installers, technicians, dealers or distributors. To contact Bose Professional or to find a dealer or environment. For more information on disposal and recycling of this product, distributor near you, visit PRO.BOSE.COM.
- Seite 3 Utilice únicamente los componentes físicos de montaje incluidos en este producto. El kit de montaje en pared MB210 está destinado únicamente para el uso con el modelo MB210. El kit de montaje en pared MB210-WR está destinado únicamente para el uso con el modelo MB210-WR.
- Seite 4 Ne montez pas le produit dans des endroits où de la condensation peut se former (MB210 seulement). Ce produit n’est pas destiné à être monté ou utilisé dans des installations humides en intérieur (par exemple piscine intérieure, parc aquatique intérieur, baignoire à...
- Seite 5 Nur fachkundige Monteure mit Wissen über sachgemäße Befestigungselemente und sichere Befestigungstechniken sollten Lautsprecher über Kopf installieren. Montieren Sie das Produkt nicht an Orten, an denen Kondenswasser auftreten kann (nur MB210). Dieses Produkt ist nicht für die Installation oder Verwendung in Bereichen mit Wassereinrichtungen in Innenräumen (zum Beispiel Schwimmbädern, Wasserparks, Räume mit...
- Seite 6 Utilizzare unicamente gli accessori di montaggio forniti con il prodotto. Il kit di montaggio a parete MB210 può essere utilizzato solo con il modello MB210. Il kit di montaggio a parete MB210-WR può essere utilizzato solo con il modello MB210-WR.
- Seite 7 Bose Professional en voor informatie over de dichtstbijzijnde dealer of distributeur, de gemeente waar u woont, de afvalverwerkingsdienst of de winkel waar u dit gaat u naar PRO.BOSE.COM.
- Seite 8 Mounting the Subwoofer with the U-Bracket ........................14 Using the Ground Feet ...................................15 MB210-WR ........................................16 Mounting the Subwoofer with the U-bracket ........................16 Recommended Amplifier Power ................................17 Recommended Signal Processing ..............................17 Technical Specifications MB210 ..........................................18 MB210-WR ........................................19 8 • English MB210/MB210-WR • Installation Guide...
- Seite 9 The MB210-WR compact subwoofer is rated IP55 and is designed for outdoor environments. WARNING: The MB210 compact subwoofer is NOT intended for outdoor environments. If the MB210 is exposed to water or moisture, the integrity of the subwoofer will be compromised.
- Seite 10 Maintaining Weather Resistance The MB210-WR compact subwoofer is water resistant and is rated IP55. To maintain water resistance, please observe the following precautions: Before, during, and after installation, check the surface of the loudspeaker enclosure to ensure that the factory-applied, weather-resistant coating has not been damaged.
- Seite 11 291 mm 11.5 in Bottom View Rear View Bracket Only 668 mm 26.3 in 300 mm 11.8 in 203 mm 8.0 in 77 mm 114 mm 3.0 in 4.5 in 100 mm 3.9 in Installation Guide • MB210/MB210-WR English • 11...
- Seite 12 184 mm 7.3 in Bottom View Rear View Bracket Only 671 mm 26.4 in 300 mm 11.8 in 203 mm 8.0 in 77 mm 114 mm 3.0 in 4.5 in 100 mm 3.9 in 12 • English MB210/MB210-WR • Installation Guide...
- Seite 13 Overview Input Panel MB210 Euroblock Connector (4-pin) NL4 connectors MB210-WR The input panel for the MB210-WR includes a single screw-terminal barrier strip. Each terminal accepts a wire gauge of 10 AWG to 18 AWG. INPUT – – THRU Barrier strip Installation Guide •...
- Seite 14 Place the washer between the U-bracket and the subwoofer. 11. Tighten the four screws with a 10-millimeter socket tool, using a torque not to exceed 13.6 to 20.3 newton·meters (10 to 15 pound·feet). 12. Connect your wiring to your subwoofer. 14 • English MB210/MB210-WR • Installation Guide...
- Seite 15 Installation Using the Ground Feet The MB210 subwoofer can be placed on the ground in either the horizontal or vertical orientation, using the ground feet. To attach the ground feet: Remove the backing from the adhesive side of the first ground foot.
- Seite 16 Place the washer between the U-bracket and the subwoofer. 14. Tighten the four screws with a 10-millimeter socket tool, using a torque not to exceed 13.6 to 20.3 newton·meters (10 to 15 pound·feet). 16 • English MB210/MB210-WR • Installation Guide...
- Seite 17 Selecting the proper amplifier size for a given loudspeaker requires analysis of the transducer long-term (or RMS) power rating, dynamic range of the input-source material (crest factor), desired sound pressure levels, and other factors. As a general guideline, to optimize MB210/MB210WR system performance, the following amplifier configurations are recommended.
- Seite 18 Bose extended-lifecycle test using pink noise filtered to meet IEC268-5, 6-dB crest factor, 500-hour duration. AES standard 2-hour duration with IEC system noise. Sensitivity measured in anechoic environment with recommended bandpass and EQ. Maximum SPL calculated using sensitivity and power ratings, exclusive of power compression. 18 • English MB210/MB210-WR • Installation Guide...
- Seite 19 Bose extended-lifecycle test using pink noise filtered to meet IEC268-5, 6-dB crest factor, 500-hour duration. AES standard 2-hour duration with IEC system noise. Sensitivity measured in anechoic environment with recommended bandpass and EQ. Maximum SPL calculated using sensitivity and power ratings, exclusive of power compression. Installation Guide • MB210/MB210-WR English • 19...
- Seite 20 ©2018 Bose Corporation, All rights reserved. Framingham, MA 01701-9168 USA PRO.BOSE.COM AM792735 Rev. 01 December 2018...
