EDIFIER NeoBuds Pro 2 Bedienungsanleitung

True W i reless Noi se Ca nce ll at io n In - Ea r Headp h o n e s
EN 1. Power ON/OFF
Indicator
1. Power ON when the case is opened.
2. Power OFF when placed in the case and the case is closed.
Note:
If there is no Bluetooth connection for 2 hours after powered on, the
earbuds will power off automatically.
2. Pairing
Pairing for the first time
1. Earbuds placed in the case and keep the case open. LEDs will be
lit one by one from left to right in a circulating pattern.
2. Select "EDIFIER NeoBuds Pro 2" in Bluetooth device setting to
connect. LEDs will blink twice and then turn off when successfully.
Pairing for new device
1. Earbuds placed in the case and keep the case open.
2. Press and hold the button on the case for about 3s. LEDs will be
lit one by one from left to right in a circulating pattern.
3. Select "EDIFIER NeoBuds Pro 2" in Bluetooth device setting to
connect. LEDs will blink twice and then turn off when successfully.
Fast Pair(Phone with Android 6.0+)
Open the charging case and keep the case next to the phone(make
sure the phone is unlocked and Bluetooth® is on), and tap the pairing
notification when the pop-up window appears to connect effortlessly.
Note:
For subsequent use, the earbuds will automatically connect to the device
used last time.
3. Reset
1. Earbuds placed in the case and keep the case open.
2. Press the button on the case 3 times to re-enter left & right
connection and clear pairing records. LEDs will be lit one by one
from sides to center in a circulating pattern and then will blink
twice when successfully.
3. Select "EDIFIER NeoBuds Pro 2" in Bluetooth device setting to
connect. LEDs will be lit one by one from left to right in a circulating
pattern, then will blink twice and turn off when successfully.
4. Auto-pause music
Remove one or both earbuds while listening to music, the music will
automatically pause; to resume the music, insert the earbud(s) back
in the ear(s). This function can be disabled or configured in "wearing
detection" settings via Edifier Connect App.
5. Charging
Indicator
6. Controls
Left Tap Panel
Note:
1. Default sound control: high noise cancellation / ambient sound.
2. Default sound modes: music mode / game mode / spatial audio.
3. lmages are for illustrative purposes only and may differ from the
actual product.
4. Download Edifier Connect App for more customizable control
settings.
For more information, please visit our website:
@Edifierglobal
Model: EDF200113
Edifier International Limited
P.O. Box 6264
General Post Office
Hong Kong
www.edifier.com
2023 Edifier International Limited. All rights reserved.
Printed in China
NOTICE:
For the need of technical improvement and system upgrade,
information contained herein may be subject to change from time
to time without prior notice.
Products of EDIFIER will be customized for different applications.
Pictures and illustrations shown on this manual may be slightly
different from actual product. If any difference is found, the actual
product prevails.
Manual
Earbuds
Place earbuds in the charging case and keep the
case closed.
Charging case
1. Please connect the case to power source with the
included Type-C charging cable for charging.
2. LEDs are steady lit when charging and off when
fully charged.
Note:
Please do not charge the earbuds when there is
sweat or other liquids inside the charging port,
which may damage the earbuds.
Input: 5V 200mA(Earbuds)
5V 1A(Charging case)
x2
x2
x2
x3
www.edifier.com
@Edifier_Global
3s
Indicator
x3
Indicator
Right Tap Panel
x2
x2
x2
x3
