WARM TIPS
1. Default equipped with 12V/5A power supply which is enough for most home
speakers,if you want higher output please prepare large power supply by yourself.
2. There is a thin protection film on both top control panel and front panel, please tear
them off before use if there are scratches.
3. When plug in AUX cable, Q1 will default enter AUX input mode. If you want
Bluetooth input, please plug out AUX cable.
4. If there is an outage or obvious distortion during use, that means the power supply
is too small to drive the speaker, please change larger power supply or turn down
the volume.
5. When there is no audio signal input or in pause status, the value of volume display
will be flashing.
HOW TO USE
1. Connect the power supply to the DC interface of Q1 amplifier firstly and then
plug it into the socket to avoid generating electric sparks, the red indicator will
be on to show that Q1 has been connected to power.
2. Wireless Input
● Correctly connect passive speakers to the banana speaker jacks output of Q1
with high-quality cables.
● Long press the power button 2S to turn it on, the indicator will be flashing blue
which means Q1 enters Bluetooth input mode and waiting for pairing.
● Turn on your audio source's Bluetooth function, search Douk Audio Q1 and click
to connect. The blue indicator will be steady on after successful connection.
3. Wired Input
● Correctly connect your audio source to the 3.5mm AUX input of Q1 with AUX
cable, and connect passive speakers to the banana speaker jacks output of Q1
with high-quality cables.
● Long press the power button 2S to turn it on, the indicator will be blue and then
auto switch to green which means Q1 enters AUX input mode.
4. Via touch screen control on the top panel, you can turn up and turn down the
volume, play or pause music.
5. After listening, please long press the power button 2S to turn it off and then
disconnect the power adapter.
Q1 Mini Bluetooth Digital Power Amplifier
User Manual
