Ceiling Light
Art.no 36-6077
Model F50600SM+IP44
Please read the entire instruction manual before using
the product and then save it for future reference. We reserve
the right for any errors in text or images and any necessary
changes made to technical data. In the event of technical
problems or other queries, please contact our Customer
Services.
Safety
Installation should only be carried out by a qualified electrician.
The product is only intended for indoor use.
The product must be installed in accordance with current
safety regulations to prevent life-threatening accidents.
The product is intended for fixed installation.
The product is intended for ceiling installation.
Only intended for indoor use (IP44).
If the plastic diffuser is damaged it must
be replaced.
Minimum distance from combustible
material: 0.1 m.
Warning: Make sure that
the power is shut off before starting
the installation.
The light source contained in this luminaire
shall only be replaced by the manufacturer
or his service agent or a similar qualified
person.
GREAT BRITAIN • CUSTOMER SERVICE tel. 020 8247 9300 e-mail customerservice@clasohlson.co.uk internet www.clasohlson.co.uk
Installation
Fixings
If the supplied fixings are not suitable for the material which
your ceiling is made of, use appropriate fixings which will
guarantee a firm anchorage.
Note: If you need to drill into the ceiling, make sure to avoid
any concealed electrical wiring.
1.
Open the ceiling light by twisting the diffuser anticlockwise
and removing it.
2.
Remove the plate holding the LED light by undoing
the 3 retaining screws.
3.
Knock out one of the pre-cut cable entries and fit
the cable gland.
4.
Pull the power supply cable through the cable gland.
5.
Fasten the ceiling light directly to the ceiling using
the 4 outermost mounting holes or fasten it to a ceiling
rose using the 2 innermost mounting holes.
6.
Connect the power supply cable to the terminal block as
shown below.
7.
Re-assemble the ceiling light in reverse order.
This ceiling light can be interconnected with multiple light
fittings of the same article number (36-6077) or with motion
sensor ceiling lights (36-6078).
Care and maintenance
Switch off the power to the ceiling light before cleaning.
Clean the light by wiping it with a soft, damp cloth. Use
a mild detergent. Never use solvents or strong, abrasive
cleaning agents.
Responsible disposal
This symbol indicates that this product should
not be disposed of with general household
waste. This applies throughout the entire EU.
In order to prevent any harm to the environment
or health hazards caused by incorrect waste
disposal, the product must be handed in for
recycling so that the material can be disposed
of in a responsible manner. When recycling
your product, take it to your local collection
facility or contact the place of purchase.
They will ensure that the product is disposed
of in an environmentally sound manner.
Specifications
Rated voltage
220–240 V AC, 50/60 Hz
Light bulb
LED light bulb (not replaceable)
Power
14.5 W
IP44
IP rating
Colour temperature
3000 K
Colour rendition
Ra 80
Luminous flux
1100 lm
Diam
34 cm
