Monitor description:
1. Brightness control
„ To increase the value, turn clockwise
2. Loudspeaker volume control
„ To increase the value, turn clockwise
3. 4.3''LED colour screen
4. Call volume adjustment (high - medium - low)
5. Soft-touch keys
6. Speaker and audio activatoin key
Soft-touch key description
„ Press the desired key once to activate the function associated with it.
Wait for approximately 1 sec. before pressing the same key again. Pressing the
same key several times in quick succession will cancel the command.
Lock-release key
Key 1 Actuator function (programmable)
Key 2 Self-ignition function (programmable)
Privacy key
Additional keys (programmable)
•
Kit with additional keys Art. 6734W sold seperately
Audio activation key
Indicator LED description:
Lock-release LED
Privacy LED
[red]
LED audio
slow flashing: door open
1 flash after pressing: door opening confirmation
continuous flashing: call in progress
steady: privacy function enabled
3 flashes (every 5 sec.): doctor function enabled
continuous flashing: device in programming mode
fixed (with call): audio activated
[6]
fixed (idle): automatic answer mode activated
continuous flashing:incoming call
