19" Basic Wallmount Cabinet
A
(1)
B
(1)
(4)
E
(1)
F
G
Cabinet Assembly
1 Place the bottom cover (A) at the desired location.
Use M5 screws to:
2 install the side panels (C).
3 install the top cover (B) onto the side panels.
4 affix rail feet (E) and then rails (D) to the side panels inside the cabinet.
Door Assembly
DO NOT OVERTIGHTEN SCREWS WHEN SECURING HINGES OR LOCK TO GLASS DOOR.
5 Remove rubber stoppers from the door hinges (F) and place them at the desired locations on the glass door (G).
6 Place rubber cushioning feet (I) at top and bottom door stops.
7 Replace door hinges over stoppers. Install glass door to cabinet.
8 Attach lock (H) to the glass door.
Models 714143, 714150, 714167, 714174, 714785, 714792, 714808, 714815
C
(2)
D
(2)
(1)
(2)
H
I
(4)
A
D
C
B
1
STEPS
Instructions
I
E
F
G
H
2
